Tractor · 1956Unverified
J.I. Case 310
J.I. Case 310 — 300 Series · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
1451 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Utility tractorReference
Built in Rock Island, Illinois, USAReference
Total built3,175Reference
Original price was $2,500 in 1958Reference
Two-wheel driveReference
Manual steeringReference
6-inch disc brakesReference
Open operator station.Reference
Variants
300diesel utilityReference
301diesel row-cropReference
302diesel high-cropReference
310gasoline utilityReference
311gasoline row-cropReference
312gasoline high-cropReference
320industrialReference
Engine
J.I. Case 2.4L 4-cyl gasolineReference
J.I. Case 2.4L 4-cyl LP GasReference
Drawbar (claimed)17.2 kWReference
Belt (claimed)21.6 kWReference
Plows3Reference
J.I. Case G148Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 105 mmReference
Air cleaneroil bathReference
Compression7.1:1Reference
Rated RPM1750Reference
Starter volts6Reference
Oil capacity3.8 LReference
Coolant capacity11.4 LReference
J.I. CaseReference
LP GasReference
Transmission
4-speed sliding gearReference
12-speedReference
8-speed mechanical shuttleReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
Clutch234.9mm dry discReference
TransmissionTripl-RangeReference
Gears12 forward and 3 reverseReference
Clutch234.9mm dry disc (master foot clutch)Reference
Clutchwet discs (traction hand clutch)Reference
Four gears (1-4) plus reverse (R) in three ranges (low, direct, high).Reference
Typemechanical shuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
Rear PTOtransmission (4-speed)Reference
Rear PTOlive (Tripl-Range)Reference
Rear PTO Type540Reference
Dimensions
Wheelbase191 cmReference
Weight1451 kgReference
Front tire6.00x16Reference
Rear tire11x24Reference
Ag front6.00x16Reference
Ag rear11x24Reference
Length317 cmReference
Height142 cmReference
Ground clearance30 cmReference
Front tread120 cmReference
Rear tread121 to 172 cmReference
310 Serial Numbers
Location:Instrument panelReference
19566050301Reference
19576075001Reference
19586095001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundpositiveReference
Battery volts6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
