Backhoe Loader · 1957Unverified
J.I. Case 310
J.I. Case 310 — Backhoe loader tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
3447 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Backhoe loader tractorReference
Total built833Reference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Disc brakesReference
Open operator station.Reference
Engine
J.I. Case 2.4L 4-cyl gasolineReference
Engine (gross)31.3 kWReference
J.I. Case G-148Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.4 LReference
Bore/Stroke86 x 105 mmReference
Power (gross)31.3 kWReference
Fuel systemupdraft carburetorReference
Air cleaneroil bathReference
Compression7.25:1Reference
Rated RPM1900Reference
Torque173.6 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity12.3 LReference
Transmission
4-speed gearReference
8-speed mechanical shuttleReference
12-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutch241mm ferrometallic dry discReference
Typemechanical shuttleReference
Gears8 forward and reverseReference
TransmissionTripl-RangeReference
Gears12 forward and 3 reverseReference
Capacities
Fuel49.2 LReference
PTO & Hydraulics
Hydraulic system41.6 LReference
Capacity41.6 LReference
Pump flow71.9 lpmReference
Rear TypeIIReference
TypeCase Eagle HitchReference
Dimensions
Wheelbase191 cmReference
Weight3447 kgReference
Ag front7.50-16Reference
Ag rear13-24Reference
Length650 cmReference
Width200 cmReference
Height147 cmReference
Height (backhoe)353 cmReference
Ground clearance30 cmReference
Front tread120 cmReference
Rear tread163 cmReference
Backhoe & Loader
Dig depth365 cmReference
Dump angle114 cmReference
Attachment overview
Front-end loaderReference
BackhoeReference
J.I. Case 31 Backhoe
Backhoe typeJ.I. Case 31 BackhoeReference
Transport height353 cmReference
Bucket width35 cmReference
Bucket width40 cmReference
Bucket width48 cmReference
Bucket width60 cmReference
Bucket width76 cmReference
Digging depth365 cmReference
Reach from pivot492 cmReference
Loading height322 cmReference
Swing Arc180°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
