Tractor · 1957Unverified
J.I. Case 351
J.I. Case 351 — Row-Crop tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
1741 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Rock Island, Illinois, USAReference
Total built905Reference
Original price was $3,100 in 1958Reference
The Case 350 was an upgraded model 300 with a larger engine. It was available as the model 350 standard or the model 351 row-crop tractor.Reference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Variants
350utility chassisReference
351row-crop chassisReference
Engine
J.I. Case 2.7L 4-cyl gasolineReference
Fuel tank69.6 LReference
Belt (claimed)31.3 kWReference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke93 x 105 mmReference
Air cleaneroil bathReference
Compression7.25:1Reference
Rated RPM1900Reference
Torque184.4 NmReference
Torque RPM1300Reference
Starter volts12Reference
Oil capacity4.7 LReference
Coolant capacity11.4 LReference
Transmission
12-speed gearReference
4-speed gearReference
TransmissionTripl-RangeReference
TypegearReference
Gears12 forward and 3 reverseReference
Four gears (1-4) plus reverse (R), with three ranges per gear (low, direct, high).Reference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Typeopen centerReference
TypeCase Eagle HitchReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase221 cmReference
Weight1741 kgReference
Front tire6.00-16Reference
Rear tire12.4-36Reference
Ag front6.00-16Reference
Ag rear12.4-36Reference
Ag rear11.2-36Reference
Ag rear13.9-36Reference
Length350 cmReference
Width205 cmReference
Height (steering wheel)162 cmReference
Height (hood)153 cmReference
Rear axle63 mmReference
Front tread137 to 198 cmReference
Rear tread137 to 223 cmReference
Capacities
Diameter23 cmReference
Width15 cmReference
RPM1290Reference
Speeds
With 11.2x36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
