Tractor · 1955Unverified
J.I. Case 410
J.I. Case 410 — 400 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2404 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built1,527Reference
Two-wheel driveReference
Final drivesbull gearReference
SteeringmanualReference
Steeringpower optionalReference
Open operator station.Reference
Variants
400diesel standardReference
401diesel row-cropReference
402diesel vineyardReference
403diesel high-cropReference
405diesel orchardReference
410gasoline standardReference
411gas row-cropReference
413gas high-cropReference
420diesel industrialReference
425gas industrialReference
Engine
J.I. Case 4.1L 4-cyl gasolineReference
J.I. Case 4.1L 4-cyl LP-gasReference
J.I. Case 4.1L 4-cyl distillateReference
Belt (claimed)37.3 kWReference
Plows4 (14-inch)Reference
J.I. CaseReference
gasolineReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 127 mmReference
Fuel systemcarburetorReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1500Reference
Idle RPM600-1665Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Coolant capacity28.0 LReference
SparkplugChampion 8Reference
Sparkplug gap0.635 mmReference
Point gap0.508 mmReference
Intake valve clearance0.305 mmReference
Exhaust valve clearance0.508 mmReference
Oil capacity8.5 LReference
LP-gasReference
4-cylinderReference
distillateReference
Transmission
8-speedReference
TransmissionPowr-rangeReference
Gears8 forward and 2 reverseReference
Clutch304.8mm dry discReference
Oil capacity56.8 LReference
Oil typeSAE 90Reference
Four gears plus reverse, with high and low ranges. All gears and ranges selected by a single lever. A "belt-neutral" position lies between the high and low ranges, intended for stationary work. Gears 7, 8, and high reverse are locked out on tractors equipped with steel wheels.Reference
Capacities
Fuel79.5 LReference
Aux. fuel3.8 LReference
Diameter26 cmReference
Width18 cmReference
RPM1166Reference
Speed976.88 meters/minReference
PTO & Hydraulics
Hydraulic system9.8 LReference
Typeopen centerReference
Capacity9.8 LReference
Pump flow45.4 lpmReference
TypeCase Eagle HitchReference
Rear PTOindependentReference
Clutchmechanical wet discReference
Rear PTO Type540 (1.375)Reference
Engine RPM558@1500Reference
Dimensions
Wheelbase208 cmReference
Weight2404 kgReference
Front tire6.00-16Reference
Rear tire13-30Reference
Ag front6.00-16Reference
Ag rear13-30Reference
Ag front7.50-16Reference
Ag rear14-30Reference
Length337 cmReference
Width169 cmReference
Clearance (front axle)44 cmReference
Front tread132 to 147 cmReference
Rear tread132 to 162 cmReference
Steering wheel157 cmReference
410 Serial Number Location
Top-right of instrument panel.Reference
410 Serial Numbers
19558060000Reference
19568080001Reference
19578100001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Battery volts6Reference
Battery AH150Reference
Battery Group4Reference
J.I. Case 410 Height
Hood154 cmReference
Exhaust226 cmReference
Speeds
With 13-30 rear tires.Reference
