Tractor · 1955Unverified
J.I. Case 411
J.I. Case 411 — 400 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Max power
26.7 kW
Weight
5563 to 6350 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Total built5,421Reference
Original price was $3,600 in 1958Reference
Two-wheel driveReference
Final drivesbull gearReference
SteeringmanualReference
Steeringpower optionalReference
Open operator station.Reference
Variants
400diesel standardReference
401diesel row-cropReference
402diesel vineyardReference
403diesel high-cropReference
405diesel orchardReference
410gasoline standardReference
411gas row-cropReference
413gas high-cropReference
420diesel industrialReference
Engine
J.I. Case 4.1L 4-cyl gasolineReference
J.I. Case 4.1L 4-cyl LP-gasReference
J.I. Case 4.1L 4-cyl distillateReference
Belt (claimed)37.3 kWReference
Plows4 (14-inch)Reference
Drawbar (tested)26.7 kWReference
Belt (tested)39.7 kWReference
J.I. CaseReference
gasolineReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 127 mmReference
Fuel systemcarburetorReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1500Reference
Idle RPM600-1665Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Coolant capacity28.0 LReference
SparkplugChampion 8Reference
Sparkplug gap0.635 mmReference
Point gap0.508 mmReference
Intake valve clearance0.305 mmReference
Exhaust valve clearance0.508 mmReference
Oil capacity8.5 LReference
LP-gasReference
4-cylinderReference
distillateReference
Belt power (max)39.7 kWReference
Max power26.7 kWReference
Transmission
8-speedReference
TransmissionPowr-rangeReference
Gears8 forward and 2 reverseReference
Clutch304.8mm dry discReference
Oil capacity56.8 LReference
Oil typeSAE 90Reference
Four gears plus reverse, with high and low ranges. All gears and ranges selected by a single lever. A "belt-neutral" position lies between the high and low ranges, intended for stationary work. Gears 7, 8, and high reverse are locked out on tractors equipped with steel wheels.Reference
Capacities
Fuel79.5 LReference
Aux. fuel3.8 LReference
Diameter26 cmReference
Width18 cmReference
RPM1166Reference
Speed976.88 meters/minReference
PTO & Hydraulics
Hydraulic system9.8 LReference
Typeopen centerReference
Capacity9.8 LReference
Valves2Reference
TypeCase Eagle HitchReference
Rear PTOindependentReference
Clutchmechanical wet discReference
Rear PTO Type540 (1.375)Reference
Engine RPM558@1500Reference
Dimensions
Wheelbase232 cmReference
Wheelbase256 cmReference
Weight5563 to 6350 poundsReference
Front tire6.00-16Reference
Rear tire12-38Reference
Ag front6.00-16Reference
Ag rear12-38Reference
Ag front6.50-16 (single)Reference
Ag front9.00-10 (single)Reference
Ag rear13-38Reference
Ag rear54" (steel)Reference
Length362 cmReference
Length386 cmReference
Width216 cmReference
Width267 cmReference
Ground clearance61 cmReference
Front tread23 to 38 cmReference
Front tread134 to 208 cmReference
Rear tread132 to 223 cmReference
Rear tread132 to 274 cmReference
2523 kgReference
2634 kgReference
Operating2880 kgReference
Ballasted4359 kgReference
Steering wheel188 cmReference
411 Serial Number Location
Top-right of instrument panel.Reference
411 Serial Numbers
19558060000Reference
19568080001Reference
19578100001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Battery volts6Reference
Battery AH150Reference
Battery Group4Reference
J.I. Case 411 Height
Hood166 cmReference
Exhaust237 cmReference
Test results
Gasoline 8-speed 2WDOctober 17 - 26, 1955Link: Nebraska Tractor Test 566 fileReference
Belt fuel use (max)17.0 l/hourReference
Drawbar performanceReference
Fuel use12.5 l/hourReference
Gear 5 used for power test.Reference
Max pull2788 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
