Tractor · 1955Unverified
J.I. Case 412
J.I. Case 412 — 400 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1977 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Orchard/Vineyard tractorReference
Built in Racine, Wisconsin, USAReference
Total built191Reference
The gas/LP Case 412 was a grove-orchard tractor in the 400 series with full swinging drawbar. The model 415 was the orchard model with an Eagle Hitch.Reference
Two-wheel driveReference
SteeringpowerReference
Engine
J.I. Case 4.1L 4-cyl gasolineReference
Belt (claimed)37.3 kWReference
Plows4 (14-inch)Reference
J.I. CaseReference
gasolineReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 127 mmReference
Compression6.5:1Reference
Rated RPM1500Reference
Coolant capacity28.0 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
Dimensions
Weight1977 kgReference
Length325 cmReference
Height (hood)143 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
