Tractor · 1981Unverified
J.I. Case 4496
J.I. Case 4496 — Four-wheel Drive (4WD) tractor · 176 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
176 hp
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Four-wheel Drive (4WD) tractorReference
Built in BrazilReference
Drive4x4 4WDReference
Steeringhydrostatic power, four-wheel steeringReference
Hydraulic dry disc brakesReference
Cab standard wth air-conditioning.Reference
Engine
Scania 11.0L 6-cyl dieselReference
Fuel tank500.0 LReference
Engine158.8 kWReference
Scania D11Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement11.0 LReference
Bore/Stroke127 x 145 mmReference
Power158.8 kWReference
Compression16:1Reference
Rated RPM2200Reference
Starter typeelectricReference
Transmission
12-speed partial power shiftReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Four ranges with three power shift gears in each range.Reference
PTO & Hydraulics
PTO (claimed)131.2 kWReference
Rear TypeIII (optional)Reference
Rear PTOindependentReference
Rear PTO Type1000Reference
Dimensions
Front tire23.1x30Reference
Rear tire23.1x30Reference
Standard tires (ag)Front: 23.1x30. Rear: 23.1x30Reference
Optional tires (ag)Front: 18.4x34. Rear: 18.4x34Reference
Electrical
Charging systemalternatorReference
Charging amps72Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
