Industrial Tractor · 1971Unverified
J.I. Case 480B
J.I. Case 480B — Industrial tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
3625 to 8950 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Industrial tractorReference
Two-wheel driveReference
Final drivesspur gearReference
Power steeringReference
Mechanical disc brakesReference
Open operator station. Optional Four-post ROPS and cab.Reference
Engine
J.I. Case 3.1L 4-cyl dieselReference
J.I. Case 2.4L 4-cyl gasolineReference
Engine (gross)30.9 kWReference
Engine (net)27.6 kWReference
J.I. Case G188DReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke97 x 105 mmReference
Power (net)27.6 kWReference
Power (gross)30.9 kWReference
Air cleanerdryReference
Compression17.5:1Reference
Rated RPM1750Reference
Torque180.3 NmReference
Torque RPM1250Reference
Starter volts12Reference
Oil capacity3.8 LReference
Coolant capacity15.6 LReference
J.I. Case G148BReference
gasolineReference
Displacement2.4 LReference
Bore/Stroke86 x 105 mmReference
Power (net)25.4 kWReference
Power (gross)28.7 kWReference
Compression7.1:1Reference
Torque172.2 NmReference
Torque RPM1200Reference
Coolant capacity13.2 LReference
Transmission
4-speed mechanical shuttleReference
8-speed mechanical shuttleReference
Typemechanical shuttleReference
Gears4 forward and reverseReference
Clutch279mm dry discReference
Oil capacity16.1 LReference
Gears8 forward and reverseReference
Capacities
Fuel83.3 LReference
PTO & Hydraulics
Hydraulic system41.6 LReference
Typeopen centerReference
Capacity41.6 LReference
Pump flow37.9 lpmReference
Pump flow79.5 lpmReference
Dimensions
Wheelbase199 cmReference
Weight3625 to 8950 poundsReference
Front tire7.50x16Reference
Rear tire13.6x24Reference
Industrial front7.50x16Reference
Industrial rear13.6x24Reference
Industrial front14.9x24Reference
Industrial front17.5Lx24Reference
Industrial front16.9x24Reference
Industrial front16.9x28Reference
Length299 cmReference
Length468 cmReference
Length662 cmReference
Width157 cmReference
Height (steering wheel)153 cmReference
Height (exhaust)231 cmReference
Ground clearance33 cmReference
Rear tread142/152/162 cmReference
Gas Shipping1644 kgReference
Diesel Shipping1735 kgReference
Diesel loader Shipping2853 kgReference
Diesel backhoe Shipping3539 kgReference
Diesel Extendahoe Shipping4059 kgReference
Max front axle15422 kgReference
Max front axle3855 kgReference
Max rear axle14968 kgReference
Max rear axle4989 kgReference
J.I. Case 480B attachments
front-end loaderReference
backhoeReference
Attachment overview
Front-end loaderReference
BackhoeReference
J.I. Case Backhoe
Backhoe typeJ.I. Case BackhoeReference
Transport height307 cmReference
Digging depth375 cmReference
Reach from pivot469 cmReference
Loading height277 cmReference
Swing Arc190°Reference
Bucket force3116 kgReference
Dipperstick force2109 kgReference
J.I. Case Extendahoe Backhoe
Backhoe typeJ.I. Case Extendahoe BackhoeReference
Digging depth (retracted stick)365 cmReference
Digging depth (extended stick)457 cmReference
Reach from pivot (retracted stick)469 cmReference
Reach from pivot (extended stick)556 cmReference
Loading height (retracted stick)283 cmReference
Loading height (extended stick)336 cmReference
Swing Arc190°Reference
Bucket force (retracted stick)2676 kgReference
Bucket force (extended stick)2676 kgReference
Dipperstick force (retracted stick)2086 kgReference
Dipperstick force (extended stick)1496 kgReference
Speeds
With 13.6x24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
