Industrial Tractor · 1978Unverified
J.I. Case 480C
J.I. Case 480C — Industrial tractor · 48 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
5284 to 10757 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Industrial tractorReference
Two-wheel driveReference
Differential lockrear standardReference
Steeringhydrostatic powerReference
Engine
J.I. Case 3.1L 4-cyl dieselReference
Engine (gross)35.8 kWReference
Engine (net)32.1 kWReference
J.I. Case G188DReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke97 x 105 mmReference
Power (net)32.1 kWReference
Power (net)35.0 kWReference
Power (gross)35.8 kWReference
Power (gross)38.8 kWReference
Air cleanerdryReference
Compression17.5:1Reference
Rated RPM1900 (8-speed)Reference
Rated RPM2100 (4-speed)Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity19.9 LReference
Transmission
8-speedReference
4-speedReference
Gears8 forward and reverseReference
Oil capacity1.9 LReference
Gears4 forward and reverseReference
Oil capacity7.6 LReference
Capacities
Fuel83.3 LReference
Steering2.8 LReference
PTO & Hydraulics
Hydraulic system45.4 LReference
Capacity45.4 LReference
Steering cap.2.8 LReference
Dimensions
Wheelbase203 cmReference
Weight5284 to 10757 poundsReference
Front tire7.50x16Reference
Rear tire14.9x24Reference
Industrial front7.50x16Reference
Industrial rear14.9x24Reference
Industrial front11Lx16Reference
Industrial rear16.9x24Reference
Industrial rear17.5Lx24Reference
Length320 cmReference
Width203 cmReference
Ground clearance27 cmReference
Front tread149 to 157 cmReference
Rear tread157 to 167 cmReference
Shipping2396 kgReference
Shipping2422 kgReference
Shipping3069 kgReference
Shipping3095 kgReference
Shipping4236 kgReference
Shipping4262 kgReference
Shipping4853 kgReference
Shipping4879 kgReference
Static Max front axle4082 kgReference
Dynamic Max front axle16329 kgReference
Static Max rear axle6123 kgReference
Dynamic Max rear axle24494 kgReference
Steering wheel175 cmReference
J.I. Case 480C attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps42Reference
Battery CCA300Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
J.I. Case Backhoe
Backhoe typeJ.I. Case BackhoeReference
Digging depth365 cmReference
Reach from pivot475 cmReference
Loading height252 cmReference
Bucket Rotation157°Reference
Swing Arc180°Reference
Bucket force2895 kgReference
Dipperstick force2033 kgReference
J.I. Case Extendahoe Backhoe
Backhoe typeJ.I. Case Extendahoe BackhoeReference
Digging depth (retracted stick)365 cmReference
Digging depth (extended stick)457 cmReference
Reach from pivot (retracted stick)472 cmReference
Reach from pivot (extended stick)561 cmReference
Loading height (retracted stick)232 cmReference
Loading height (extended stick)264 cmReference
Bucket Rotation147°Reference
Swing Arc180°Reference
Bucket force (retracted stick)2808 kgReference
Bucket force (extended stick)2808 kgReference
Dipperstick force (retracted stick)2022 kgReference
Dipperstick force (extended stick)1457 kgReference
J.I. Case 480C Height
ROPS259 cmReference
Cab259 cmReference
Exhaust266 cmReference
Speeds
With 14.9x24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
