Tractor · 1983Unverified

J.I. Case 4894

Name: J.I. Case 4894
Brand: J.I. Case

J.I. Case 4894 — 4WD 94 Series · 253 hp. Reference specifications; pending source verification.

The J.I. Case 4894 is a tractor with a rated power of 253 hp, placing it at the more powerful end of its class. It was manufactured between 1983 and 1984. This model is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive with a powershift transmission. It has an operating weight of 11680 kg and is suitable for operations covering 1,500+ acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

253 hp

Max power

163.1 kW

Weight

11680 kg

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

253 hp

Recorded weight

11680 kg

Transmissions

12-speed

Production years

1983-1984

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Four-wheel Drive (4WD) tractorReference

Built in Racine, Wisconsin, USAReference

Total built872Reference

Original price$100,600 (1985)Reference

Drive4x4 4WDReference

Steeringhydraulic, front, rear or four-wheel crab steeringReference

Hydraulic dry disc brakesReference

Silent Guardian cab standardReference

Engine

Saab-Scania 11.0L 6-cyl dieselReference

Engine223.7 kWReference

Drawbar (tested)163.1 kWReference

Saab-ScaniaReference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement11.0 LReference

Bore/Stroke127 x 145 mmReference

Power223.7 kWReference

Air cleanerdual paper elementsReference

Compression14.7:1Reference

Rated RPM2200Reference

Torque1145.8 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity45.4 LReference

Coolant capacity41.6 LReference

Power at rated engine speed189.0 kWReference

Max power163.1 kWReference

Transmission

12-speedReference

Transmissionpartial power shiftReference

Gears12 forward and 4 reverseReference

Clutchhydraulic wet discReference

Four ranges (1-4) with three power shift gears (1-3) plus reverse in each range. Both shift levers mounted on the dashboard. Range shift lever is to the left in a H-pattern. Gear shift is an inline pattern on the right.Reference

PTO & Hydraulics

PTO (claimed)188.7 kWReference

PTO (tested)189.0 kWReference

Hydraulic system68.1 LReference

Typeclosed centerReference

Capacity68.1 LReference

Pressure162.0 barReference

Valves4Reference

Total flow102.2 lpmReference

Rear TypeIII (optional)Reference

Rear lift (at 24"/610mm)5783 kgReference

Rear PTOindependent (optional)Reference

Rear PTO Type1000Reference

Engine RPM1000@2200Reference

Capacities

Fuel567.8 LReference

Dimensions

Wheelbase279 cmReference

Weight11680 kgReference

Front tire18.4-34Reference

Rear tire18.4-34Reference

Ag front18.4-34Reference

Ag rear18.4-34Reference

Length601 cmReference

Width251 cmReference

Width335 cmReference

Height (exhaust)317 cmReference

Operating weight11680 kgReference

Ballasted weight12909 kgReference

Ground clearance45 cmReference

4894 Serial Numbers

Location:Data plates located at forward-right corner in top of the tractor cab.Reference

19848865000Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Test results

Diesel 12-speed 4WDOctober 22 - 29, 1979Link: Nebraska Tractor Test 1330 fileReference

PTO performanceReference

Fuel use58.7 l/hourReference

Drawbar performanceReference

Fuel use58.3 l/hourReference

Gear 3-2 used for power test.Reference

Max pull12531 kgReference

Gear 1-2 used for pull test.Reference

Speeds

With 23.1x30 tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
