Tractor · 1958Unverified

J.I. Case 511-B

Name: J.I. Case 511-B
Brand: J.I. Case

J.I. Case 511-B — 500B Series · 45 hp. Reference specifications; pending source verification.

The J.I. Case 511-B is a tractor with a rated output of 45 hp, categorising it as a lighter model within its class. Produced from 1958 to 1960, this tractor features a 4-cylinder petrol liquid-cooled engine, coupled with two-wheel drive and a 4-speed gearbox. Its listed operating weight is 2141 kg, with a suitable operational area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Max power

29.1 kW

Weight

2141 kg

Catalogue coverage

Variants represented

Richest spec table

86 rows

Recorded power

45 hp

Recorded weight

2141 kg

Transmissions

4-speed gear

Production years

1958-1960

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Row-Crop tractorReference

Built in Rock Island, Illinois, USAReference

Total built1,481Reference

Original price was $3,700 in 1960Reference

Two-wheel driveReference

Manual steeringReference

Disc brakesReference

Open operator station.Reference

Variants

510ButilityReference

511Brow-cropReference

Engine

J.I. Case 2.7L 4-cyl gasolineReference

Drawbar (tested)29.1 kWReference

Belt (tested)33.6 kWReference

J.I. Case G164Reference

gasolineReference

4-cylinderReference

liquid-cooled vertical I-headReference

Displacement2.7 LReference

Bore/Stroke93 x 105 mmReference

Air cleaneroil bathReference

Compression7.3:1Reference

Rated RPM2000Reference

StarterelectricReference

Starter volts12Reference

Coolant capacity11.4 LReference

Oil capacity4.7 LReference

Oil change100 hReference

Belt power (max)33.6 kWReference

Max power29.1 kWReference

Transmission

4-speed gearReference

12-speed gearReference

TypegearReference

Gears4 forward and 1 reverseReference

Oil capacity41.6 LReference

TransmissionTripl-RangeReference

Gears12 forward and 3 reverseReference

Four gears, plus reverse, in three ranges.Reference

PTO & Hydraulics

PTO (claimed)33.6 kWReference

Hydraulic system11.4 LReference

Typeopen centerReference

Capacity11.4 LReference

Pressure82.7 barReference

TypeCase Eagle HitchReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1925Reference

Capacities

Fuel52.2 LReference

Diameter23 cmReference

Width16 cmReference

RPM1360Reference

Speed1002.79 meters/minReference

Dimensions

Wheelbase220 cmReference

Weight2141 kgReference

Front tire6.00-16Reference

Rear tire12.4-36Reference

Ag front6.00-16Reference

Ag rear12.4-36Reference

Ag front6.50-16Reference

Ag rear11.2-36Reference

Ag rear13.9-36Reference

Length350 cmReference

Width205 cmReference

Height (steering wheel)166 cmReference

Height (exhaust)217 cmReference

Operating weight2141 kgReference

Ballasted weight3385 kgReference

Front tread23/38 cmReference

Front tread137 to 198 cmReference

Front tread111 to 152 cmReference

Rear tread137 to 223 cmReference

J.I. Case 511-B attachments

front-end loaderReference

511-B Serial Numbers

Location:Serial number plate on instrument panelReference

19586095001Reference

19596120001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundpositiveReference

Battery volts12Reference

Battery AH50Reference

Test results

Gasoline 12-speed 2WDApril 14 - 18, 1958Link: Nebraska Tractor Test 646 fileReference

Belt fuel use (max)15.5 l/hourReference

Drawbar performanceReference

Gear 5 used for power test.Reference

Max pull2556 kgReference

Gear 1 used for pull test.Reference

Speeds

With 12.4-36 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
