Industrial Tractor · 1999Unverified
J.I. Case 550H
J.I. Case 550H — H Series · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
14317 to 14960 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
BulldozerReference
DrivecrawlerReference
Final drivesbull gearReference
Hydraulic wet disc brakesReference
Four-post ROPS canopy.Reference
Engine
Case 3.9L 4-cyl dieselReference
Engine (gross)55.9 kWReference
Engine (net)50.0 kWReference
Case 4-390Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Power (net)50.0 kWReference
Power (gross)55.9 kWReference
Rated RPM2200Reference
Idle RPM800-2420Reference
Torque259.0 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity10.4 LReference
Coolant capacity15.6 LReference
Transmission
4-speed torque converterReference
Typetorque converterReference
Gears4 forward and reverseReference
Capacities
Fuel115.4 LReference
PTO & Hydraulics
Hydraulic system39.0 LReference
Typeopen centerReference
Capacity39.0 LReference
Pressure172.4 barReference
Pump flow82.9 lpmReference
Dimensions
Weight14317 to 14960 poundsReference
16-inch tracksReference
LT dozer length396 cmReference
WT/LGP dozer length396 cmReference
Height (ROPS)258 cmReference
LGP Height (ROPS)260 cmReference
LT Gauge134 cmReference
WT Gauge162 cmReference
LGP Gauge162 cmReference
LT Operating6494 kgReference
WT Operating6622 kgReference
LGP Operating6785 kgReference
Ripper576 kgReference
J.I. Case 550H attachments
bladeReference
Electrical
Charging systemalternatorReference
Charging amps65Reference
Battery CCA700Reference
Battery volts12Reference
J.I. Case 550H Tracks
LT width40 cmReference
LT length on ground198 cmReference
LT area on ground1.6 m²Reference
LT ground pressure0.4 barReference
WT width50 cmReference
WT length on ground198 cmReference
WT area on ground2.0 m²Reference
WT ground pressure0.3 barReference
LGP width66 cmReference
LGP length on ground198 cmReference
LGP area on ground2.6 m²Reference
LGP ground pressure0.3 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
