Industrial Tractor · 1980Unverified

J.I. Case 580D Construction King

Name: J.I. Case 580D Construction King
Brand: J.I. Case

J.I. Case 580D Construction King — Industrial tractor · 60 hp. Reference specifications; pending source verification.

The J.I. Case 580D Construction King is a 60 hp industrial tractor that falls within the lighter end of its class. It was manufactured from 1980 to 1983 and features a 4-cylinder diesel liquid-cooled engine, paired with a hydrostatic transmission and two-wheel drive. This model is suited to operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

60 hp

Catalogue coverage

Variants represented

Richest spec table

56 rows

Recorded power

60 hp

Transmissions

4-speed

Production years

1980-1983

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Industrial tractorReference

Two-wheel driveReference

Steeringhydrostatic powerReference

Engine

J.I. Case 3.4L 4-cyl dieselReference

Engine (gross)44.7 kWReference

Engine (net)41.0 kWReference

J.I. Case G207DReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke102 x 105 mmReference

Power (net)41.0 kWReference

Power (gross)44.7 kWReference

Air cleanerdryReference

Compression17:1Reference

Rated RPM2100Reference

Torque217.0 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity6.6 LReference

Coolant capacity12.3 LReference

Transmission

4-speedReference

Gears4 forward and reverseReference

Transaxpe Oil capacity18.9 LReference

Shuttle Oil capacity7.6 LReference

Four speed sliding spur gear transmission with torque converter and power shuttle. Synchronized up-shifts from 2 to 3, and from 3 to 4. Synchronized down-shift from 4 to 3.Reference

Capacities

Fuel83.3 LReference

PTO & Hydraulics

Hydraulic system47.3 LReference

Capacity47.3 LReference

Steering flow26.5 lpmReference

Steering press.137.9 barReference

Dimensions

Front tire7.50x16Reference

Rear tire14.9x24Reference

Industrial front7.50x16Reference

Industrial rear14.9x24Reference

Industrial front8.00x16Reference

Industrial front11Lx16Reference

Industrial rear16.9x24Reference

Industrial rear17.5Lx24Reference

Static Max front axle5216 kgReference

Dynamic Max front axle19958 kgReference

Static Max rear axle6123 kgReference

Dynamic Max rear axle24494 kgReference

580D Serial Numbers

19809050041Reference

19819051570Reference

19829062065Reference

19839081281Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps42Reference

Battery CCA625Reference

Battery volts12Reference

Speeds

With 17.5Lx24 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
