Backhoe Loader · 1995Unverified

J.I. Case 590 Super L

Name: J.I. Case 590 Super L
Brand: J.I. Case

J.I. Case 590 Super L — Backhoe loader tractor · 95 hp. Reference specifications; pending source verification.

The J.I. Case 590 Super L is a backhoe loader with a rated output of 95 hp — putting it around the middle of its class for power. It was produced from 1995 to 2000. Power comes from a 4-cylinder turbocharged diesel liquid-cooled engine, driving through mechanical front-wheel drive with a 4-speed gearbox. Listed weight is 15396 to 17130 pounds, and it is aimed at jobs of around 200–800 ac. Detailed specifications in both UK and US units follow below.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

95 hp

Weight

15396 to 17130 pounds

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

95 hp

Recorded weight

6983 kg

Transmissions

4-speed power shuttle

Production years

1995-2000

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Backhoe loader tractorReference

Drive4x2 2WD: 4x4 MFWD 4WDReference

Power steeringReference

Engine

Case 3.9L 4-cyl dieselReference

Engine (gross)70.8 kWReference

Engine (net)65.6 kWReference

Case 4T-390Reference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.9 LReference

Bore/Stroke102 x 120 mmReference

Power (net)65.6 kWReference

Power (gross)70.8 kWReference

Rated RPM2200Reference

Torque381.0 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity11.0 LReference

Coolant capacity15.8 LReference

Coolant capacity16.5 LReference

Transmission

4-speed power shuttleReference

Typepower shuttleReference

Gears4 forward and reverseReference

Capacities

Fuel118.8 LReference

PTO & Hydraulics

Hydraulic system124.9 LReference

Typeopen centerReference

Capacity124.9 LReference

Pressure203.4 barReference

Pump flow119.2 lpmReference

Pump flow41.6 lpmReference

Total flow160.9 lpmReference

Dimensions

2WD Wheelbase213 cmReference

4WD Wheelbase214 cmReference

Weight15396 to 17130 poundsReference

Front tire14.5x16.1Reference

Rear tire21Lx24Reference

2WD Industrial front14.5x16.1Reference

4WD Industrial front14x17.5Reference

Industrial rear21Lx24Reference

Length716 cmReference

Width236 cmReference

2WD ROPS Weight6983 kgReference

4WD Cab Weight7770 kgReference

Ground clearance37 cmReference

2WD Front tread174 cmReference

4WD Front tread186 cmReference

Rear tread176 cmReference

Backhoe & Loader

Dig depth485 cmReference

Dump angle114 cmReference

Electrical

Charging systemalternatorReference

Charging amps65Reference

Battery CCA685Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Case Backhoe

Backhoe typeCase BackhoeReference

Digging depth485 cmReference

2-Foot flat digging depth482 cmReference

Reach from pivot599 cmReference

Loading height342 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force5953 kgReference

Dipperstick force3832 kgReference

Case Extendahoe Backhoe

Backhoe typeCase Extendahoe BackhoeReference

Digging depth (retracted stick)485 cmReference

Digging depth (extended stick)607 cmReference

2-Foot flat digging depth (retracted stick)482 cmReference

2-Foot flat digging depth (extended stick)604 cmReference

Reach from pivot (retracted stick)599 cmReference

Reach from pivot (extended stick)718 cmReference

Loading height (retracted stick)347 cmReference

Loading height (extended stick)419 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force (retracted stick)5953 kgReference

Bucket force (extended stick)5953 kgReference

Dipperstick force (retracted stick)3832 kgReference

Dipperstick force (extended stick)2721 kgReference

J.I. Case 590 Super L Height

ROPS266 cmReference

Cab271 cmReference

Exhaust264 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
