Industrial Tractor · 1980Unverified
J.I. Case 648
J.I. Case 648 — 600 Series · 18 hp. Reference specifications; pending source verification.
The J.I. Case 648 is a compact industrial tractor with a rated output of 18 hp. It was manufactured from 1980 to 1988 and features a 2-cylinder petrol air-cooled engine, which drives the two-wheel drive system. The listed weight of the model ranges from 1273 to 2750 pounds. It is designed to perform tasks on land areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1273 to 2750 pounds
Catalogue coverage
Variants represented
2
Richest spec table
70 rows
Recorded power
18 hp
Recorded weight
577 kg
Production years
1980-1988
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Industrial tractorReference
Two-wheel driveReference
Power steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
Onan 0.8L 2-cyl gasolineReference
Engine13.4 kWReference
Onan B48MReference
gasolineReference
2-cylinderReference
air-cooledReference
Displacement0.8 LReference
Bore/Stroke83 x 73 mmReference
Power13.4 kWReference
Compression6.6:1Reference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RH18YReference
Sparkplug gap0.635 mmReference
Oil capacity1.9 LReference
Transmission
hydraulic driveReference
TransmissionHy-DriveReference
Typehydraulic driveReference
Gearsinfinite forward and reverse (2-range)Reference
Capacities
Fuel18.9 LReference
PTO & Hydraulics
Hydraulic system12.3 LReference
Hydraulic system18.9 LReference
Typeopen centerReference
Capacity12.3 LReference
Capacity18.9 LReference
Pressure172.4 barReference
Pump flow26.5 lpmReference
Rear Type0Reference
Typesleeve hitchReference
Dimensions
Wheelbase121 cmReference
Weight1273 to 2750 poundsReference
Front tire18x8.50-8Reference
Rear tire26x12.00-12Reference
Industrial front18x8.50-8Reference
Industrial rear26x12.00-12Reference
Length274 cmReference
Length406 cmReference
Width104 cmReference
Height (steering wheel)113 cmReference
Weight577 kgReference
Weight1247 kgReference
Ground clearance20 cmReference
J.I. Case 648 attachments
44" mid-mount mower deckReference
48" mid-mount mower deckReference
front-end loaderReference
backhoeReference
648 Serial Numbers
Location:Serial number plate on the left side of tractor, ahead of the steering column.Reference
Electrical
GroundnegativeReference
Charging systemflywheel alternatorReference
Charging amps15Reference
Charging volts12Reference
Battery volts12Reference
Battery AH32Reference
Attachment overview
44" mid-mount mower deckReference
48" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
J.I. Case Backhoe
Backhoe typeJ.I. Case BackhoeReference
Transport height165 cmReference
Digging depth236 cmReference
Reach from pivot281 cmReference
Loading height152 cmReference
Swing Arc167°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
