Industrial Tractor · 1995Unverified
J.I. Case 650G
J.I. Case 650G — G Series · 88 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
88 hp
Weight
7166 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. Case (a part of CaseIH)Reference
BulldozerReference
DrivecrawlerReference
Final drivesbull gearReference
Hydraulic wet disc brakesReference
Four-post ROPS.Reference
Engine
J.I. Case 3.9L 4-cyl dieselReference
Engine (gross)65.6 kWReference
Engine (net)59.7 kWReference
J.I. Case 4T-390Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Power (net)59.7 kWReference
Power (gross)65.6 kWReference
Rated RPM2200Reference
Torque329.5 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
4-speed torque converterReference
Typetorque converterReference
Gears4 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure186.2 barReference
Pump flow90.5 lpmReference
Dimensions
Weight7166 kgReference
18-inch tracksReference
Operating weight7166 kgReference
Gauge152 cmReference
J.I. Case 650G attachments
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
J.I. Case 650G Tracks
Width45 cmReference
Length on ground205 cmReference
Area on ground1.9 m²Reference
Ground pressure0.4 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
