Industrial Tractor · 1999Unverified
J.I. Case 650H
J.I. Case 650H — H Series · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
16091 to 17440 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
BulldozerReference
DrivecrawlerReference
Final drivesbull gearReference
Four-post ROPS canopy. Cab optional with air-conditioning.Reference
Engine
Case 3.9L 4-cyl dieselReference
Engine (gross)59.7 kWReference
Engine (net)55.8 kWReference
Case 4T-390Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke102 x 120 mmReference
Power (net)55.8 kWReference
Power (gross)59.7 kWReference
Rated RPM2200Reference
Idle RPM800-2420Reference
Torque310.5 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity18.9 LReference
Transmission
4-speed torque converterReference
Typetorque converterReference
Gears4 forward and reverseReference
Capacities
Fuel177.9 LReference
PTO & Hydraulics
Hydraulic system41.3 LReference
Typeopen centerReference
Capacity41.3 LReference
Dimensions
Weight16091 to 17440 poundsReference
16-inch tracksReference
LT dozer length429 cmReference
WT dozer length429 cmReference
LGP dozer length429 cmReference
Height (ROPS)271 cmReference
Height (cab)304 cmReference
Ground clearance40 cmReference
LT Gauge144 cmReference
WT Gauge170 cmReference
LGP Gauge170 cmReference
LT Operating7298 kgReference
WT Operating7620 kgReference
LGP Operating7910 kgReference
Ripper635 kgReference
J.I. Case 650H attachments
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
J.I. Case 650H Tracks
LT width40 cmReference
LT length on ground210 cmReference
LT area on ground1.7 m²Reference
LT ground pressure0.4 barReference
WT width55 cmReference
WT length on ground210 cmReference
WT area on ground2.3 m²Reference
WT ground pressure0.3 barReference
LGP width63 cmReference
LGP length on ground210 cmReference
LGP area on ground2.7 m²Reference
LGP ground pressure0.3 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
