Tractor · 1958Unverified
J.I. Case 711-B
J.I. Case 711-B — 700B Series · 53 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
53 hp
Max power
38.9 kW
Weight
2912 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Total built980Reference
Original price was $4,400 in 1960Reference
Two-wheel driveReference
SteeringpowerReference
Differential mechanical disc brakesReference
Open operator station.Reference
Variants
700Bdiesel standardReference
701Bdiesel row-cropReference
702Bdiesel WesternReference
703Bdiesel high-cropReference
710Bgas standardReference
711Bgas row-cropReference
712Bgas WesternReference
713Bgas high-cropReference
Engine
J.I. Case 4.1L 4-cyl gasolineReference
J.I. Case 4.1L 4-cyl LP gasReference
Belt (claimed)40.3 kWReference
Drawbar (tested)35.8 kWReference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 127 mmReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1500Reference
Starter volts12Reference
LP gasReference
Compression8.0:1Reference
Max power38.9 kWReference
Max power34.8 kWReference
Power at rated engine speed39.8 kWReference
Max power35.8 kWReference
Transmission
8-speed gearReference
TransmissionDual-RangeReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (tested)39.8 kWReference
Rear PTO Type540 (1.375)Reference
Power at rated PTO speed38.8 kWReference
Dimensions
Wheelbase234 cmReference
Weight2912 kgReference
Front tire6.00-16Reference
Rear tire15.5-38Reference
Ag front6.00-16Reference
Ag rear15.5-38Reference
Length364 cmReference
Height (hood)167 cmReference
Operating weight2912 kgReference
Ballasted weight4263 kgReference
J.I. Case 711-B attachments
front-end loaderReference
711-B Serial Number Location
Serial number plate on the right side of the instrument panel.Reference
Test results
NTTL 678: gasoline 8-speed 2WDReference
NTTL 694: LP gas 8-speed 2WDReference
Gasoline 8-speed 2WDOctober 27 - November 13, 1958Link: Nebraska Tractor Test 678 fileReference
PTO performanceReference
Fuel use17.0 l/hourReference
Drawbar performanceReference
Gear 5 used for power test.Reference
Max pull3431 kgReference
Gear 1 used for pull test.Reference
LP gas 8-speed 2WDApril 22 - May 15, 1959Link: Nebraska Tractor Test 694 fileReference
Fuel use20.4 l/hourReference
Fuel use20.1 l/hourReference
Fuel use20.8 l/hourReference
Max pull3398 kgReference
Gear 2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
