Tractor · 1960Unverified
J.I. Case 741
J.I. Case 741 — 730 Series · 58 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
58 hp
Max power
37.7 kW
Weight
3175 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Original price$6,100 (1969)Reference
The 741 was the spark-ignition version of the Case 730 series row-crop tractor. The 741 was available with gasoline or LP-gas engines, and tricycle or adjustible wide-front end.Reference
Two-wheel driveReference
SteeringmanualReference
Steeringpower optionalReference
Differential disc brakesReference
Open operator station.Reference
Variants
730standard-front dieselReference
731row-crop dieselReference
732Western Special dieselReference
733high-clearance dieselReference
734orchard dieselReference
740standard-front gasReference
741row-crop gasReference
742Western Special gasReference
743high-clearance gasReference
744orchard gasReference
Engine
J.I. Case 4.1L 4-cyl gasolineReference
J.I. Case 4.1L 4-cyl LP gasReference
Fuel tank65.5 LReference
Fuel tank84.0 LReference
Plows5Reference
Drawbar (tested)39.2 kWReference
J.I. Case PowrdyneReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement4.1 LReference
Bore/Stroke102 x 127 mmReference
Air cleaneroil bathReference
Compression6.88:1Reference
Rated RPM1700 (Dual-Range)Reference
Rated RPM1900 (Case-o-Matic)Reference
Starter volts12Reference
LP gasReference
Compression8.2:1Reference
Power at rated engine speed43.2 kWReference
Max power37.7 kWReference
Power at rated engine speed43.1 kWReference
Max power38.4 kWReference
Power at rated engine speed42.6 kWReference
Max power38.8 kWReference
Power at rated engine speed43.2 kWReference
Max power39.2 kWReference
Transmission
8-speed torque converterReference
8-speedReference
TransmissionCase-o-MaticReference
Typetorque converterReference
Gears8 forward and 2 reverseReference
TransmissionDual-RangeReference
Clutchmechanical dry discReference
PTO & Hydraulics
PTO (tested)43.2 kWReference
Typeopen centerReference
TypeCase Eagle HitchReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type1000Reference
Power at rated PTO speed41.2 kWReference
Power at rated PTO speed41.0 kWReference
Dimensions
Wheelbase234 cmReference
Weight3175 kgReference
Front tire6.00-16Reference
Rear tire15.5-38Reference
Ag front6.00-16Reference
Ag rear15.5-38Reference
Length364 cmReference
Width216 cmReference
Height (hood)167 cmReference
Operating weight3175 kgReference
Ballasted weight4302 kgReference
Ground clearance50 cmReference
J.I. Case 741 attachments
front-end loaderReference
741 Serial Number Location
Plate on instrument panelReference
741 Serial Numbers
19608160001Reference
19618168801Reference
19628190001Reference
19638208001Reference
19648229001Reference
19658253501Reference
19668279001Reference
19678306501Reference
19688332101Reference
19698356251Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Test results
NTTL 778: gasoline Case-o-Matic 2WDReference
NTTL 779: gasoline Dual-Range 2WDReference
NTTL 781: LP gas Case-o-Matic 2WDReference
NTTL 782: LP gas Dual-Range 2WDReference
Gasoline Case-o-Matic 2WDNovember 2 - 12, 1960Link: Nebraska Tractor Test 778 fileReference
PTO performanceReference
Fuel use19.3 l/hourReference
Fuel use17.8 l/hourReference
Drawbar performanceReference
Fuel use19.7 l/hourReference
Gear 4 used for power test.Reference
Max pull3407 kgReference
Gear 2-Direct used for pull test.Reference
Gasoline Dual-Range 2WDNovember 3 - 12, 1960Link: Nebraska Tractor Test 779 fileReference
Fuel use18.5 l/hourReference
Max pull3455 kgReference
Gear 2 used for pull test.Reference
LP gas Case-o-Matic 2WDNovember 4 - 19, 1960Link: Nebraska Tractor Test 781 fileReference
Fuel use27.3 l/hourReference
Fuel use24.6 l/hourReference
Fuel use26.5 l/hourReference
Gear 3 used for power test.Reference
Max pull3459 kgReference
LP gas Dual-Range 2WDNovember 7 - 19, 1960Link: Nebraska Tractor Test 782 fileReference
Fuel use23.5 l/hourReference
Fuel use24.2 l/hourReference
Max pull3477 kgReference
Gear 4 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
