Backhoe Loader · 1988Unverified
J.I. Case 780D
J.I. Case 780D — Backhoe loader tractor · 124 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
124 hp
Weight
23264 to 27424 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Backhoe loader tractorReference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS canopy standard. Optional cab with available air-conditioning.Reference
Engine
J.I. Case 5.9L 6-cyl dieselReference
Engine (gross)92.5 kWReference
Engine (net)83.5 kWReference
J.I. Case 6T-590Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke102 x 120 mmReference
Power (net)83.5 kWReference
Power (gross)92.5 kWReference
Air cleanerdryReference
Compression17.5:1Reference
Rated RPM2200Reference
Torque501.7 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.4 LReference
Coolant capacity25.6 LReference
Transmission
3-speed power shiftReference
Typepower shiftReference
Gears3 forward and 2 reverseReference
Power shift transmission with torque converter and power shuttle.Reference
Capacities
Fuel162.8 LReference
PTO & Hydraulics
Hydraulic system53.7 LReference
Typeopen centerReference
Capacity53.7 LReference
Pump flow119.2 lpmReference
Pump flow105.2 lpmReference
Steering flow105.2 lpmReference
Steering press.120.7 barReference
Dimensions
Wheelbase220 cmReference
Weight23264 to 27424 poundsReference
Front tire14.00x17.5Reference
Rear tire21Lx24Reference
Industrial front14.00x17.5Reference
Industrial rear21Lx24Reference
Industrial front15x9.15Reference
Industrial rear18.4x28Reference
Industrial rear21Lx28Reference
Length751 cmReference
Width246 cmReference
Ground clearance52 cmReference
Front tread199 cmReference
Rear tread181 cmReference
Shipping10552 kgReference
Shipping12439 kgReference
Max front axle10092 kgReference
Max front axle20189 kgReference
Max rear axle12236 kgReference
Max rear axle24471 kgReference
Steering wheel222 cmReference
Backhoe & Loader
Dig depth551 cmReference
Dump angle132 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Batteries2Reference
Battery CCA685Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
J.I. Case 18-foot Backhoe
Backhoe typeJ.I. Case 18-foot BackhoeReference
Transport height400 cmReference
Digging depth551 cmReference
2-Foot flat digging depth548 cmReference
Reach from pivot668 cmReference
Loading height386 cmReference
Bucket Rotation156°Reference
Swing Arc180°Reference
Bucket force6187 kgReference
Dipperstick force4975 kgReference
J.I. Case Extendahoe Backhoe
Backhoe typeJ.I. Case Extendahoe BackhoeReference
Transport height400 cmReference
Digging depth (retracted stick)556 cmReference
Digging depth (extended stick)670 cmReference
2-Foot flat digging depth (retracted stick)548 cmReference
2-Foot flat digging depth (extended stick)668 cmReference
Reach from pivot (retracted stick)665 cmReference
Reach from pivot (extended stick)777 cmReference
Loading height (retracted stick)386 cmReference
Loading height (extended stick)441 cmReference
Bucket Rotation156°Reference
Swing Arc180°Reference
Bucket force (retracted stick)6233 kgReference
Bucket force (extended stick)6233 kgReference
Dipperstick force (retracted stick)5032 kgReference
Dipperstick force (extended stick)3691 kgReference
J.I. Case 780D Height
Cab295 cmReference
Exhaust287 cmReference
Backhoe400 cmReference
Speeds
With 18.4x24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
