Lawn Tractor · 1984Unverified
J.I. Case 80 XC
J.I. Case 80 XC — Riding lawn mower · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
150 kg
Hover a source tag to verify
Overview
DistributorJ.I. CaseReference
ManufacturerIngersollReference
Riding lawn mowerReference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station.Reference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & StrattonReference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
friction discReference
Typefriction discReference
Gearsinfinite forward and reverseReference
Dimensions
Wheelbase119 cmReference
Weight150 kgReference
Front tire4.00-5Reference
Rear tire6.50-8Reference
Lawn/turf front4.00-5Reference
Lawn/turf rear6.50-8Reference
Length153 cmReference
Width74 cmReference
Height91 cmReference
Ground clearance5 cmReference
J.I. Case 80 XC attachments
30" mid-mount mower deckReference
Electrical
GroundnegativeReference
Battery volts12Reference
30" Mower deck
Typemid-mount J.I. Case M43Reference
Type1-blade with manual liftReference
Cutting width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
