Tractor · 1958Unverified
J.I. Case 800-B
J.I. Case 800-B — 800 B Series · 54 hp. Reference specifications; pending source verification.
The J.I. Case 800-B is a compact tractor with a rated output of 54 hp, produced from 1958 to 1959. It features a 4-cylinder diesel liquid-cooled engine, coupled with an 8-speed gearbox and two-wheel drive. The 800-B is designed for applications covering approximately 200 acres. Specifications for the tractor in both the UK and US are detailed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Catalogue coverage
Variants represented
2
Richest spec table
52 rows
Recorded power
54 hp
Transmissions
8-speed torque converter
Production years
1958-1959
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built255Reference
Two-wheel driveReference
SteeringpowerReference
Mechanical disc brakesReference
Open operator station.Reference
Variants
800Bdiesel standardReference
801Bdiesel row-cropReference
802Bdiesel Western specialReference
803Bdiesel high-cropReference
810Bgas standardReference
811Bgas row-cropReference
812Bgas Western specialReference
813Bgas high-cropReference
Engine
J.I. Case 4.4L 4-cyl dieselReference
Fuel tank83.3 LReference
Belt (claimed)40.3 kWReference
Plows5Reference
J.I. CaseReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
Air cleaneroil bathReference
Compression15:1Reference
Rated RPM1800Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity28.4 LReference
Transmission
8-speed torque converterReference
TransmissionCase-O-MaticReference
Typetorque converterReference
Gears8 forward and 2 reverseReference
Clutchhydraulic wet discReference
Four gears, plus reservse, in two ranges controlled with a single shift lever. Torque converter transmission with bypass to lock in direct drive.Reference
PTO & Hydraulics
TypeCase Eagle Hitch (optional)Reference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase210 cmReference
Length339 cmReference
Height168 cmReference
Height (hood)155 cmReference
Front tread132/147 cmReference
Rear tread132/142/152/162 cmReference
J.I. Case 800-B attachments
front-end loaderReference
Capacities
Diameter26 cmReference
Width18 cmReference
RPM1128Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
