Tractor · 1958Unverified
J.I. Case 810
J.I. Case 810 — Agricultural Crawler tractor · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Max power
28.8 kW
Weight
6804 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Agricultural Crawler tractorReference
Built in Churubusco, Indiana, USAReference
DrivecrawlerReference
Hydraulic disc brakesReference
Open operator station.Reference
Variants
800industrial crawlerReference
810ag crawlerReference
Engine
Continental 4.5L 4-cyl dieselReference
Continental 4.5L 4-cyl gasolineReference
Engine (gross)59.7 kWReference
Plows5Reference
Drawbar (tested)28.8 kWReference
Continental HD-277Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.5 LReference
Bore/Stroke102 x 140 mmReference
Power (gross)59.7 kWReference
Air cleaneroil bathReference
Compression15:1Reference
Rated RPM2250Reference
Torque276.6 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts24Reference
ContinentalReference
gasolineReference
Compression7:1Reference
Max power28.8 kWReference
Transmission
4-speed power shiftReference
TransmissionTerramaticReference
Typepower shiftReference
Gears4 forward and reverseReference
Clutchhydraulic discReference
PTO & Hydraulics
Pump flow113.6 lpmReference
Dimensions
Wheelbase185 cmReference
Weight6804 kgReference
15-inch tracksReference
Length355 cmReference
Width175 cmReference
Height (steering wheel)181 cmReference
Operating weight6804 kgReference
Gauge137 cmReference
J.I. Case 810 attachments
bladeReference
810 Serial Numbers
19577080001Reference
19587080541Reference
19597080999Reference
FAQ: How to read a serial number table.Reference
J.I. Case 810 Tracks
Width38 cmReference
Test results
Diesel 4-speed crawlerAugust 14 - 28, 1959Link: Nebraska Tractor Test 713 fileReference
Drawbar performanceReference
Fuel use17.4 l/hourReference
Gear 2 used for power test.Reference
Max pull6393 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
