Tractor · 1960Unverified
J.I. Case 831
J.I. Case 831 — 830 Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Max power
43.5 kW
Weight
6250 to 6692 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Original price was $6,000 in 1969Reference
Two-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Mechanical dry disc brakesReference
Open operator station.Reference
Variants
830diesel standard-frontReference
831diesel row-cropReference
832diesel Western SpecialReference
833diesel high-cropReference
840gas standard-frontReference
841gas row-cropReference
842gas Western SpecialReference
843gas high-cropReference
Engine
J.I. Case 4.9L 4-cyl dieselReference
Fuel tank83.3 LReference
Fuel tank106.0 LReference
Belt (claimed)49.2 kWReference
Plows5Reference
Drawbar (tested)43.5 kWReference
J.I. Case PowrcelReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke111 x 127 mmReference
Compression15:1Reference
Rated RPM1700 (Dual-Range)Reference
Rated RPM1900 (Case-O-Matic)Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity28.4 LReference
Power at rated engine speed47.5 kWReference
Max power43.5 kWReference
Power at rated engine speed47.5 kWReference
Max power40.5 kWReference
Power at rated engine speed47.9 kWReference
Max power43.0 kWReference
Transmission
8-speed gearReference
8-speed torque converterReference
TransmissionDual RangeReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
Oil capacity8.5 LReference
Oil capacity64.4 LReference
TransmissionCase-O-MaticReference
Typetorque converterReference
Clutchwet discReference
PTO & Hydraulics
PTO (tested)47.9 kWReference
Typeopen centerReference
Rear TypeIIReference
ControlDraft-o-matic load/depth controlReference
TypeCase Eagle HitchReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed45.5 kWReference
Power at rated PTO speed44.8 kWReference
Dimensions
Wheelbase234 cmReference
Wheelbase258 cmReference
Weight6250 to 6692 poundsReference
Front tire6.00-16Reference
Rear tire13.6-38Reference
Ag front6.00-16Reference
Ag rear13.6-38Reference
Length364 cmReference
Length387 cmReference
Width216 cmReference
Height167 cmReference
Front tread23/30/38 cmReference
Front tread104 to 157 cmReference
Front tread121 to 185 cmReference
Front tread134 to 208 cmReference
Rear tread132 to 223 cmReference
Rear tread132 to 243 cmReference
Rear tread132 to 274 cmReference
2835 kgReference
2958 kgReference
2897 kgReference
3035 kgReference
J.I. Case 831 attachments
front-end loaderReference
831 Serial Number Location
Plate on right side of instrument panel. Case-O-Matics marked as 831C.Reference
831 Serial Numbers
19608160001Reference
19618168801Reference
19628190001Reference
19639208001Reference
19648229001Reference
19658253501Reference
19668279001Reference
19678306501Reference
19688332101Reference
19698356251Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter26 cmReference
Width18 cmReference
RPM1322 (Dual Range)Reference
RPM1027 (Case-O-Matic 540)Reference
RPM1261 (Case-O-Matic 1000)Reference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Batteries2Reference
Battery volts6Reference
Test results
NTTL 736: diesel Case-O-Matic 2WDReference
NTTL 737: diesel Dual-Range 2WDReference
NTTL 917: diesel Dual-Range 2WD CKReference
Diesel Case-O-Matic 2WDApril 5 - 19, 1960Link: Nebraska Tractor Test 736 fileReference
PTO performanceReference
Fuel use17.4 l/hourReference
Fuel use15.9 l/hourReference
Drawbar performanceReference
Gear 4 used for power test.Reference
Max pull3606 kgReference
Gear 2 used for pull test.Reference
Diesel Dual-Range 2WDApril 5 - 23, 1960Link: Nebraska Tractor Test 737 fileReference
Fuel use16.3 l/hourReference
Max pull3565 kgReference
Diesel Dual-Range 2WD CKOctober 7 - 16, 1965Link: Nebraska Tractor Test 917 fileReference
Fuel use18.2 l/hourReference
Max pull3751 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
