Industrial Tractor · 1995Unverified
J.I. Case 850G
J.I. Case 850G — G Series · 99 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
99 hp
Weight
17100 to 18370 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. Case (a part of CaseIH)Reference
BulldozerReference
DrivecrawlerReference
Final drivesbull gearReference
Hydraulic wet disc brakesReference
Four-post ROPS.Reference
Engine
J.I. Case 5.9L 6-cyl dieselReference
Engine (gross)73.8 kWReference
Engine (net)66.4 kWReference
J.I. Case 6T-590Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement5.9 LReference
Bore/Stroke102 x 120 mmReference
Power (net)66.4 kWReference
Power (gross)73.8 kWReference
Rated RPM2200Reference
Torque359.3 NmReference
Torque RPM1200Reference
Starter typeelectricReference
Transmission
4-speed torque converterReference
Typetorque converterReference
Gears4 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure186.2 barReference
Pump flow90.5 lpmReference
Dimensions
Weight17100 to 18370 poundsReference
18-inch tracksReference
LT Operating weight7756 kgReference
LGP Operating weight8332 kgReference
LT Gauge152 cmReference
LGP Gauge177 cmReference
J.I. Case 850G attachments
bladeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
J.I. Case 850G Tracks
LT width45 cmReference
LT length on ground223 cmReference
LT area on ground2.0 m²Reference
LT ground pressure0.4 barReference
LGP width73 cmReference
LGP length on ground223 cmReference
LGP area on ground3.3 m²Reference
LGP ground pressure0.2 barReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
