Tractor · 1957Unverified
J.I. Case 900-B
J.I. Case 900-B — 900B Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Max power
49.4 kW
Weight
3855 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built5,640Reference
Original price$6,000 (1960)Reference
Two-wheel driveReference
Steeringpower assistReference
Disc brakesReference
Open operator station.Reference
Variants
900BdieselReference
910BLP-gasReference
Engine
J.I. Case 6.2L 6-cyl dieselReference
Plows5-6Reference
Drawbar (tested)49.4 kWReference
J.I. CaseReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.2 LReference
Bore/Stroke102 x 127 mmReference
Air cleaneroil bathReference
Compression15:1Reference
Rated RPM1500Reference
Starter volts12Reference
Oil capacity11.4 LReference
Power at rated engine speed52.4 kWReference
Max power49.4 kWReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Clutchoil cushionReference
PTO & Hydraulics
PTO (tested)52.4 kWReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase213 cmReference
Weight3855 kgReference
Front tire7.50-18Reference
Rear tire15-34Reference
Ag front7.50-18Reference
Ag rear15-34Reference
Length358 cmReference
Operating weight3855 kgReference
Ballasted weight5976 kgReference
Front tread139 cmReference
Rear tread171 cmReference
900-B Serial Number Location
Serial number tag on the right side of the Case 900, ahead of the dashboard.Reference
900-B Serial Numbers
19578100001Reference
19588120001Reference
19598140001Reference
FAQ: How to read a serial number table.Reference
Test results
Diesel 6-speed 2WDApril 20 - 29, 1959Link: Nebraska Tractor Test 692 fileReference
PTO performanceReference
Fuel use18.2 l/hourReference
Drawbar performanceReference
Fuel use18.5 l/hourReference
Gear 3 used for power test.Reference
Max pull4259 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
