Tractor · 1957Unverified
J.I. Case 910-B
J.I. Case 910-B — 900B Series · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Max power
46.3 kW
Weight
3878 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built1,000Reference
Original price$5,500 (1960)Reference
Two-wheel driveReference
Steeringpower assistReference
Disc brakesReference
Open operator station.Reference
Variants
900BdieselReference
910BLP-gasReference
Engine
J.I. Case 6.2L 6-cyl LP gasReference
Fuel tank124.9 LReference
Plows5-6Reference
Drawbar (tested)46.3 kWReference
J.I. CaseReference
LP gasReference
6-cylinderReference
liquid-cooledReference
Displacement6.2 LReference
Bore/Stroke102 x 127 mmReference
Compression7.5:1Reference
Rated RPM1350Reference
Starter volts12Reference
Oil capacity11.4 LReference
Power at rated engine speed53.0 kWReference
Max power46.3 kWReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Clutchoil cushionReference
PTO & Hydraulics
PTO (tested)53.0 kWReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase213 cmReference
Weight3878 kgReference
Front tire7.50-18Reference
Rear tire15-34Reference
Ag front7.50-18Reference
Ag rear15-34Reference
Length358 cmReference
Operating weight3878 kgReference
Ballasted weight6692 kgReference
Front tread139 cmReference
Rear tread171 cmReference
Test results
Diesel 6-speed 2WDApril 29 - May 15, 1959Link: Nebraska Tractor Test 696 fileReference
PTO performanceReference
Fuel use26.9 l/hourReference
Drawbar performanceReference
Gear 3 used for power test.Reference
Max pull4762 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
