Tractor · 1960Unverified
J.I. Case 930
J.I. Case 930 — 30 Series · 81 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
81 hp
Max power
52.9 kW
Weight
4014 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Original price was $6,700 in 1969Reference
The 930 Comfort King (930 CK) was introduced in 1962.Reference
Two-wheel driveReference
Steeringpower assistReference
Differential mechanical dry disc brakesReference
Open operator station.Reference
Variants
930diesel standardReference
931diesel general-purposeReference
940gas standardReference
941gas general-purposeReference
Engine
J.I. Case 6.6L 6-cyl dieselReference
Fuel tank113.6 LReference
Fuel tank181.7 LReference
Belt (claimed)61.9 kWReference
Plows6Reference
Drawbar (tested)52.9 kWReference
J.I. CaseReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke105 x 127 mmReference
Compression15.2:1Reference
Rated RPM1600 (early)Reference
Rated RPM1800 (late)Reference
Firing order1-5-3-6-2-4Reference
Starter volts12Reference
Power at rated engine speed60.1 kWReference
Max power52.9 kWReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 1 reverseReference
Clutchhand-operated discReference
PTO & Hydraulics
PTO (tested)60.1 kWReference
TypeDual-ControlReference
Valves1 or 2Reference
Pump flow56.8 lpmReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed59.0 kWReference
Dimensions
Wheelbase213 cmReference
Weight4014 kgReference
Front tire7.50-18Reference
Rear tire15x34Reference
Ag front7.50-18Reference
Ag rear15x34Reference
Length358 cmReference
Width213 cmReference
Height (hood)163 cmReference
Operating weight4014 kgReference
Ballasted weight6851 kgReference
Front tread144 cmReference
Rear tread171 cmReference
930 Serial Number Location
Plate on instrument panelReference
930 Serial Numbers
19608160001Reference
19618168801Reference
19628190001Reference
19638208001Reference
19648229001Reference
19658253501Reference
19668279001Reference
19678306501Reference
19688332101Reference
19698356251Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter29 cmReference
Width20 cmReference
RPM1007Reference
Test results
Diesel 6-speed 2WDApril 14 - May 5, 1960Link: Nebraska Tractor Test 741 fileReference
PTO performanceReference
Fuel use20.1 l/hourReference
Fuel use19.7 l/hourReference
Drawbar performanceReference
Fuel use20.4 l/hourReference
Gear 3 used for power test.Reference
Max pull4973 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
