Tractor · 1929Unverified

J.I. Case CC

Name: J.I. Case CC
Brand: J.I. Case

J.I. Case CC — C Series · 17 hp. Reference specifications; pending source verification.

The J.I. Case CC is a tractor with a rated power of 17 hp, situated at the lighter end of its class. It was manufactured from 1929 to 1939. The tractor is equipped with a 4-cylinder petrol liquid-cooled engine and features two-wheel drive with a 3-speed gearbox. It has an operating weight of 1859 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Max power

16.9 kW

Weight

1859 kg

Catalogue coverage

Variants represented

Richest spec table

73 rows

Recorded power

17 hp

Recorded weight

1859 kg

Transmissions

3-speed gear

Production years

1929-1939

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

Row-Crop tractorReference

Total built28,656Reference

The Case CC was the row-crop version of the standard C. It was available in with tricycle front, adjustable wide front, and fixed wide front ends.Reference

Two-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Variants

CC-3row-cropReference

CC-4wide-frontReference

CCShigh cropReference

CstandardReference

Engine

J.I. Case 4.3L 4-cyl gasolineReference

Fuel tank68.1 LReference

Aux. fuel7.6 LReference

Drawbar (claimed)12.7 kWReference

Belt (claimed)20.1 kWReference

Plows2 (14-inch)Reference

Drawbar (tested)16.9 kWReference

Belt (tested)21.6 kWReference

J.I. CaseReference

gasolineReference

4-cylinderReference

liquid-cooled vertical I-headReference

Displacement4.3 LReference

Bore/Stroke98 x 140 mmReference

Compression4.88:1Reference

Rated RPM1100Reference

Firing order1-2-4-3Reference

Coolant capacity18.9 LReference

Belt power (max)21.6 kWReference

Max power16.9 kWReference

Transmission

3-speed gearReference

TypegearReference

Gears3 forward and 1 reverseReference

Clutchmechanical wet discReference

Oil typeSAE 150Reference

PTO & Hydraulics

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Engine RPM536@1100Reference

Dimensions

Weight1859 kgReference

Front tire25x4Reference

Rear tire48x8Reference

Ag front25x4 steelReference

Ag rear48x8 steelReference

Ag front5.50-16Reference

Ag rear9.00-36Reference

Length347 cmReference

Width121 cmReference

Height143 cmReference

Rear tread121 to 213 cmReference

CC Serial Number Location

Serial number plate on the tractor's instrument panel.Reference

CC Serial Numbers

19293xx2xxReference

19303xx3xxReference

19313xx4xxReference

19323xx5xxReference

19333xx6xxReference

19343xx7xxReference

19353xx8xxReference

19363xx9xxReference

19374xx0xxReference

19384200001Reference

19394300001Reference

FAQ: How to read a serial number table.Reference

Capacities

Diameter29 cmReference

Width15 cmReference

RPM846Reference

Speed762.00 meters/minReference

Test results

Kerosene 3-speed 2WDSeptember 10 - 18, 1929Link: Nebraska Tractor Test 169 fileReference

Belt fuel use (max)11.0 l/hourReference

Drawbar performanceReference

Gear 3 used for power test.Reference

Max pull1338 kgReference

Gear 3 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
