The J.I. Case CF 250 is a tractor with a rated power of 25 hp, positioning it at the lower end of its class in terms of power output. Manufactured between 1962 and 1966, this model features a 4-cylinder diesel liquid-cooled engine, paired with two-wheel drive and an 8-speed gearbox. It has a listed operating weight of 1599 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1599 kg
Catalogue coverage
Variants represented
2
Richest spec table
52 rows
Recorded power
25 hp
Recorded weight
1599 kg
Transmissions
8-speed gear
Production years
1962-1966
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Utility tractorReference
Built in Vierzon, FranceReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical drum brakesReference
Open operator station.Reference
Engine
Indenor 1.8L 4-cyl dieselReference
Engine18.6 kWReference
Indenor XDP85Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke85 x 80 mmReference
Power18.6 kWReference
Fuel systemindirect injectionReference
Air cleaneroil bathReference
Compression21:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.0 LReference
Coolant capacity10.2 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range.Reference
Capacities
Fuel50.0 LReference
PTO & Hydraulics
Hydraulic system8.5 LReference
Capacity8.5 LReference
Rear TypeII/IReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Mid PTOindependentReference
Mid PTO Type1000Reference
Dimensions
Wheelbase175 cmReference
Weight1599 kgReference
Front tire5.00-15Reference
Rear tire10-28Reference
Ag front5.00-15Reference
Ag rear10-28Reference
Ag rear11-28Reference
Length298 cmReference
Width164 cmReference
Height159 cmReference
Ground clearance48 cmReference
Front tread121 to 179 cmReference
Rear tread121 to 192 cmReference
Speeds
With 10-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
