Industrial Tractor · 1929Unverified
J.I. Case CI
J.I. Case CI — Industrial tractor · 35 hp. Reference specifications; pending source verification.
The J.I. Case CI is a lightweight industrial tractor with a power output of approximately 35 hp, placing it at the lower end of its class. In production from 1929 to 1940, this model features a 4-cylinder petrol liquid-cooled engine and a two-wheel drive system with a 3-speed gearbox, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
35 hp
Transmissions
3-speed gear
Production years
1929-1940
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Industrial tractorReference
Total built791Reference
The CI was available in a narrow-tread option with an overall width of 48 inches.Reference
Two-wheel driveReference
Final drivesroller chainReference
Manual steeringReference
Open operator station.Reference
Variants
Cfarm modelReference
Engine
J.I. Case 4.3L 4-cyl gasolineReference
Fuel tank60.6 LReference
Aux. fuel7.6 LReference
Engine26.1 kWReference
Belt (claimed)20.1 kWReference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke98 x 140 mmReference
Power26.1 kWReference
Rated RPM1100Reference
Starter typehand-crankReference
Coolant capacity18.9 LReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Front tire30x5Reference
Rear tire40x8Reference
Industrial front30x5Reference
Industrial rear40x8Reference
Industrial front29x5Reference
Industrial rear40x10Reference
Industrial rear38x7Reference
Rear axle73 mmReference
Speeds
With 40x8 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
