Tractor · 1939Unverified
J.I. Case D
J.I. Case D — D Series · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2086 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Standard-tread tractorReference
Built in Racine, Wisconsin, USAReference
Total built14,396Reference
Original price was $2,500 in 1953Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Dstandard-treadReference
DCrow-cropReference
DIindustrialReference
DOorchardReference
DEXexportReference
Engine
J.I. Case 4.3L 4-cyl gasolineReference
J.I. Case 4.3L 4-cyl LP gasReference
Gas Fuel tank71.9 LReference
Gas Fuel tank64.3 LReference
Aux. fuel7.6 LReference
Drawbar (claimed)23.1 kWReference
Plows3Reference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement4.3 LReference
Bore/Stroke98 x 140 mmReference
Compression4.88:1Reference
Rated RPM1200Reference
Starter volts6Reference
Coolant capacity24.6 LReference
LP gasReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Clutchmechanical wet discReference
PTO & Hydraulics
PTO (claimed)26.1 kWReference
TypeCase Eagle HitchReference
Rear PTOcontinuousReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase168 cmReference
Weight2086 kgReference
Front tire7.50-16Reference
Rear tire12.75x24Reference
Ag front7.50-16Reference
Ag rear12.75x24Reference
Ag front28x5 (steel)Reference
Ag rear42x11.25 (steel)Reference
Length294 cmReference
Width156 cmReference
Height (hood)136 cmReference
Clearance (front axle)35 cmReference
Clearance (rear axle)49 cmReference
Rear tread135 cmReference
D Serial Number Location
Serial number plate on the D's instrument panel, above the steering shaft or the toolbox. Also cut into the casting flange where the engine and transmission meet, on the left.Reference
D Serial Numbers
19394300001Reference
19404400001Reference
19414500001Reference
19424600001Reference
19434700001Reference
19444800001Reference
19454900001Reference
19465000001Reference
19475100001Reference
19485200001Reference
19495300001Reference
19505400001Reference
19515500001Reference
19525600001Reference
19535700001Reference
19538300001Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter31 cmReference
Width18 cmReference
RPM818Reference
Speed798.58 meters/minReference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Battery volts6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
