Tractor · 1935Unverified
J.I. Case RC
J.I. Case RC — Row-Crop tractor · 11 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
11 hp
Max power
10.6 kW
Weight
1834 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Racine, Wisconsin, USAReference
Total built15,948Reference
Two-wheel driveReference
Final drivesbull gearReference
Manual steeringReference
Open operator station.Reference
Variants
Rstandard treadReference
RCrow-cropReference
ROorchardReference
RIindustrialReference
Engine
Waukesha 2.2L 4-cyl gasolineReference
Fuel tank56.8 LReference
Drawbar (claimed)8.2 kWReference
Belt (claimed)12.7 kWReference
Plows2Reference
Drawbar (tested)10.6 kWReference
Belt (tested)14.8 kWReference
WaukeshaReference
gasolineReference
4-cylinderReference
liquid-cooled vertical L-headReference
Displacement2.2 LReference
Bore/Stroke83 x 102 mmReference
Air cleaneroil bathReference
Rated RPM1425Reference
Oil capacity4.7 LReference
Coolant capacity16.1 LReference
Belt power (max)14.8 kWReference
Max power10.6 kWReference
Transmission
3-speed gearReference
4-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
The four-speed gearbox became standard in 1939, tractor serial number 4325361.Reference
Gears4 forward and 1 reverseReference
Clutchmechanical wet discReference
PTO & Hydraulics
Rear PTO Type540 (1.125)Reference
Dimensions
Weight1834 kgReference
Front tire5x15Reference
Rear tire10x38Reference
Ag front5x15Reference
Ag front7.50x10 (single-front)Reference
Ag rear10x38Reference
Ag front6x20.5 (steel)Reference
Ag rear6x48 (steel)Reference
Length316 cmReference
Width160 cmReference
Height111 cmReference
Rear tread111 to 203 cmReference
RC Serial Numbers
19353xx8xxReference
19363xx9xxReference
19374xx0xxReference
19384200001Reference
19394300001Reference
19404400001Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter25 cmReference
Width15 cmReference
RPM991Reference
Speed792.48 meters/minReference
Test results
Gasoline 3-speed 2WDApril 7 - 16, 1936Link: Nebraska Tractor Test 251 fileReference
Belt fuel use (max)8.7 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
