Industrial Tractor · 1942Unverified
J.I. Case SI
J.I. Case SI — Industrial tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
1984 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Industrial tractorReference
Built in Racine, Wisconsin, USAReference
Total built3740Reference
The model SI was the industrial version of the Case model S tractor.Reference
Two-wheel driveReference
Manual steeringReference
Disc brakesReference
Open operator station. Steel pan seat with spring suspension.Reference
Variants
Sfarm tractorReference
SCrow-crop farm tractorReference
SIindustrialReference
Engine
J.I. Case 2.5L 4-cyl gasolineReference
J.I. Case 2.7L 4-cylReference
Fuel tank53.0 LReference
Aux. fuel4.7 LReference
Engine26.1 kWReference
Drawbar (claimed)11.9 kWReference
Belt (claimed)15.7 kWReference
Plows2 (14-inch)Reference
J.I. CaseReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 102 mmReference
Rated RPM1550Reference
Coolant capacity15.1 LReference
Displacement2.7 LReference
Bore/Stroke92 x 102 mmReference
Power26.1 kWReference
Oil capacity4.7 LReference
Transmission
4-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears4 forward and 1 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow75.7 lpmReference
Rear PTOcontinuousReference
Rear PTO Type541Reference
Dimensions
Wheelbase167 cmReference
Weight1984 kgReference
Rear tire12.00-24Reference
Industrial rear12.00-24Reference
Length275 cmReference
Width142 cmReference
Clearance (front axle)31 cmReference
Clearance (rear axle)31 cmReference
Front tread132 cmReference
Rear tread123 cmReference
Steering wheel164 cmReference
J.I. Case SI Height
Hood130 cmReference
Exhaust188 cmReference
Speeds
With 12.00-24 rear tires.Reference
