Tractor · 1942Unverified

J.I. Case VAH

Name: J.I. Case VAH
Brand: J.I. Case

J.I. Case VAH — High-Clearance tractor · 17 hp. Reference specifications; pending source verification.

The J.I. Case VAH is a compact tractor model with a rated output of 17 hp. It was manufactured from 1942 to 1955 and features a 4-cylinder petrol liquid-cooled engine. The tractor is equipped with a 4-speed gearbox and two-wheel drive, weighing 1315 kg. It is designed for tasks involving approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Weight

1315 kg

Catalogue coverage

Variants represented

Richest spec table

94 rows

Recorded power

17 hp

Recorded weight

1315 kg

Transmissions

4-speed unsynchronized gear

Production years

1942-1955

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerJ.I. CaseReference

High-Clearance tractorReference

Built in Rock Island, Illinois, USAReference

Total built2,016Reference

Two-wheel driveReference

Manual steeringReference

Differential mechanical disc brakesReference

Open operator station.Reference

Variants

VAstandard treadReference

VACtricycle row-cropReference

VAIindustrialReference

VAIWwarehouseReference

VAHhigh-clearanceReference

VASoffset high-clearanceReference

VAC-11single-front wheelReference

VAC-12dual-front row-cropReference

VAC-13adjustable wide-front row-cropReference

VAC-14lowered version of VAC-13Reference

VAO-15similar to VAOReference

Engine

J.I. Case 2.0L 4-cyl distillateReference

J.I. Case 2.0L 4-cyl gasolineReference

Fuel tank35.0 LReference

Aux. fuel3.8 LReference

Drawbar (claimed)9.7 kWReference

Plows2Reference

J.I. CaseReference

distillateReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke83 x 95 mmReference

Air cleaneroil bathReference

Compression5:1Reference

Rated RPM1425Reference

Firing order1-3-4-2Reference

Starter volts6Reference

Coolant capacity12.3 LReference

SparkplugChampion 15AReference

SparkplugAC 87Reference

Sparkplug gap0.635 mmReference

Point gap0.508 mmReference

Intake valve clearance0.356 mmReference

Exhaust valve clearance0.356 mmReference

Oil capacity3.8 LReference

gasolineReference

Compression6:1Reference

Transmission

4-speed unsynchronized gearReference

Typeunsynchronized gearReference

Gears4 forward and 1 reverseReference

Clutch228.6mm dry discReference

Oil capacity26.5 LReference

Oil type[0oC]Reference

32oF [0oC]↑: SAE140Reference

32oF [0oC]↓: SAE90Reference

PTO & Hydraulics

PTO (claimed)12.7 kWReference

TypeCase Eagle HitchReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Engine RPM525@1425Reference

Dimensions

Wheelbase213 cmReference

Weight1315 kgReference

Front tire6.00-16Reference

Rear tire9-36Reference

Ag front6.00-16Reference

Ag rear9-36Reference

Height (hood)161 cmReference

Shipping weight1315 kgReference

Front tread154 to 215 cmReference

Rear tread152 to 223 cmReference

VAH Serial Numbers

Location:Serial number plate on the tractor's instrument panel.Reference

19424600001Reference

19434700001Reference

19444800001Reference

19454900001Reference

19465000001Reference

19475100001Reference

19485200001Reference

19495300001Reference

19505400001Reference

19515500001Reference

19525600001Reference

19535700001Reference

19545800001Reference

19555900001Reference

FAQ: How to read a serial number table.Reference

Capacities

Diameter26 cmReference

Width15 cmReference

RPM969Reference

Speed792.48 meters/minReference

Electrical

GroundpositiveReference

Charging systemgeneratorReference

Charging amps12Reference

Battery volts6Reference

Speeds

With 9-36 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
