Tractor · 1940Unverified
J.I. Case VC
J.I. Case VC — V Series · 24 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1950 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Row-Crop tractorReference
Built in Rock Island, Illinois, USAReference
Total built12462Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Variants
VstandardReference
VCrow-cropReference
VOorchardReference
VIindustrialReference
Engine
Continental 2.0L 4-cyl gasolineReference
Fuel tank37.9 LReference
Plows2Reference
ContinentalReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke76 x 111 mmReference
Air cleaneroil bathReference
Rated RPM1425Reference
Starter typehand-crankReference
Starter typeelectric (optional)Reference
SparkplugAC 75Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)17.9 kWReference
Typepower lift (optional)Reference
Rear PTO Type540 (1.125)Reference
Dimensions
Weight1950 kgReference
Front tire5.00-15Reference
Rear tire9-32Reference
Ag front5.00-15Reference
Ag rear9-32Reference
VC Serial Numbers
1940VC4400001Reference
1941VC4500001Reference
1942VC4600001Reference
FAQ: How to read a serial number table.Reference
Capacities
Diameter26 cmReference
Width16 cmReference
RPM969Reference
Speed792.48 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
