Industrial Tractor · 1981Unverified
J.I. Case W-20B
J.I. Case W-20B — Wheel Loader · 114 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
114 hp
Weight
9608 kg
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Wheel LoaderReference
Four-wheel driveReference
Articulated power steeringReference
Hydro-pneumatic disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
J.I. Case 6.6L 6-cyl dieselReference
Engine (gross)85.0 kWReference
Engine (net)76.8 kWReference
J.I. Case A401BDReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke105 x 127 mmReference
Power (net)76.8 kWReference
Power (gross)85.0 kWReference
Air cleanerdryReference
Rated RPM2200Reference
Torque404.1 NmReference
Torque RPM1450Reference
Starter typeelectricReference
Oil capacity11.4 LReference
Coolant capacity49.2 LReference
Transmission
4-speed power shiftReference
Typepower shiftReference
Gears4 forward and 2 reverseReference
Capacities
Fuel189.2 LReference
PTO & Hydraulics
Hydraulic system109.8 LReference
Typeopen centerReference
Capacity109.8 LReference
Pressure148.2 barReference
Pump flow181.7 lpmReference
Dimensions
Wheelbase274 cmReference
Weight9608 kgReference
Front tire17.5x25Reference
Rear tire17.5x25Reference
Industrial front17.5x25Reference
Industrial rear17.5x25Reference
Length614 cmReference
Width231 cmReference
Height (steering wheel)248 cmReference
Height (cab)312 cmReference
Operating weight9608 kgReference
Ground clearance43 cmReference
Front tread185 cmReference
Rear tread185 cmReference
J.I. Case W-20B attachments
front-end loaderReference
Speeds
With 17.5x25 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
