Industrial Tractor · 1978Unverified
J.I. Case W-4
J.I. Case W-4 — Wheel Loader · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
4310 to 4568 pounds
Hover a source tag to verify
Overview
ManufacturerJ.I. CaseReference
Wheel LoaderReference
Four-wheel driveReference
Articulated power steeringReference
Mechanical disc brakesReference
Two-post ROPS with FOPS canopy. Cab optional.Reference
Engine
Mitsubishi 2.1L 4-cyl dieselReference
Engine (gross)29.8 kWReference
Engine (net)27.6 kWReference
Mitsubishi 4DQ50Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke84 x 94 mmReference
Power (net)27.6 kWReference
Power (gross)29.8 kWReference
Air cleanerdryReference
Rated RPM3000Reference
Torque118.0 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity9.5 LReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Capacities
Fuel50.0 LReference
PTO & Hydraulics
Hydraulic system56.8 LReference
Typeopen centerReference
Capacity56.8 LReference
Dimensions
Wheelbase144 cmReference
Weight4310 to 4568 poundsReference
Front tire12.5Lx15Reference
Rear tire12.5Lx15Reference
Industrial front12.5Lx15Reference
Industrial rear12.5Lx15Reference
Length367 cmReference
Height (ROPS)231 cmReference
Ground clearance23 cmReference
Front tread118 cmReference
Rear tread118 cmReference
Shipping1955 kgReference
Operating2072 kgReference
Ballasted2449 kgReference
J.I. Case W-4 attachments
front-end loaderReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Battery AH90Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
