The Jinma JM-160 is a tractor model with a rated power of 16 hp, categorising it as a lighter model within its class. It is powered by a 1-cylinder diesel engine and is equipped with a 6-speed gearbox. The tractor has an operating weight of 950 kg, making it suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
16 hp
Weight
950 kg
Catalogue coverage
Variants represented
2
Richest spec table
24 rows
Recorded power
16 hp
Recorded weight
950 kg
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
Engine
Jinma 1-cyl dieselReference
Engine11.9 kWReference
JinmaReference
dieselReference
1-cylinderReference
Power11.9 kWReference
Rated RPM2300Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear Type0Reference
Rear lift305 kgReference
Rear PTOliveReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase139 cmReference
Weight950 kgReference
Front tire4.00-14Reference
Rear tire8.3-20Reference
Ag front4.00-14Reference
Ag rear8.3-20Reference
Length247 cmReference
Width123 cmReference
Height128 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
