The Jinma JM-180 is a tractor rated at roughly 18 hp, which places it at the lighter end of its class. Under the hood is a 2-cylinder diesel engine, paired with a 6-speed gearbox. It has a listed operating weight of 970 kg, and it suits operations of up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
970 kg
Catalogue coverage
Variants represented
2
Richest spec table
24 rows
Recorded power
18 hp
Recorded weight
970 kg
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
Engine
Jinma 2-cyl dieselReference
Engine13.4 kWReference
JinmaReference
dieselReference
2-cylinderReference
Power13.4 kWReference
Rated RPM2200Reference
Transmission
6-speedReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear Type0Reference
Rear lift336 kgReference
Rear PTOliveReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase149 cmReference
Weight970 kgReference
Front tire4.00-16Reference
Rear tire8.3-24Reference
Ag front4.00-16Reference
Ag rear8.3-24Reference
Length254 cmReference
Width123 cmReference
Height128 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
