Tractor · Unverified
Jinma JM-184
Jinma JM-184 · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Weight
1200 kg
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
Four-wheel driveReference
Engine
Jinma 2-cyl dieselReference
Engine13.4 kWReference
JinmaReference
dieselReference
2-cylinderReference
Power13.4 kWReference
Rated RPM2200Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Rear Type0Reference
Rear lift366 kgReference
Rear PTOliveReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase151 cmReference
Weight1200 kgReference
Front tire6.00-12Reference
Rear tire8.3-24Reference
Ag front6.00-12Reference
Ag rear8.3-24Reference
Length266 cmReference
Width123 cmReference
Height130 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
