Jinma JM-250
Jinma JM-250 — Compact Utility tractor · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1195 kg
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Compact Utility tractorReference
Built in Yancheng City, ChinaReference
Two-wheel driveReference
Variants
JM-2502WDReference
JM-2544WDReference
Engine
Yangdong 1.5L 3-cyl dieselReference
2-cyl dieselReference
Engine18.6 kWReference
Yangdong Y385TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke85 x 90 mmReference
Power18.6 kWReference
Compression22:1Reference
Rated RPM2350Reference
Firing order1-3-2Reference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity8.0 LReference
2-cylinderReference
Rated RPM2300Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Capacities
Fuel22.0 LReference
PTO & Hydraulics
Hydraulic system9.0 LReference
Capacity9.0 LReference
Valves1Reference
Rear TypeIReference
Rear lift396 kgReference
Rear PTOliveReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase163 cmReference
Weight1195 kgReference
Front tire4.00-16Reference
Rear tire9.5-24Reference
Ag front4.00-16Reference
Ag rear9.5-24Reference
Length284 cmReference
Width144 cmReference
Height132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
