Tractor · Unverified
Jinma JM-450
Jinma JM-450 · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1889 kg
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Built in Yancheng City, ChinaReference
Two-wheel driveReference
Engine
Jinma 3.0L 3-cyl dieselReference
Engine33.6 kWReference
JinmaReference
dieselReference
3-cylinderReference
Displacement3.0 LReference
Bore/Stroke105 x 117 mmReference
Power33.6 kWReference
Rated RPM2200Reference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift764 kgReference
Rear PTOliveReference
Rear PTO Type540, 720, 1000Reference
Dimensions
Wheelbase187 cmReference
Weight1889 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Length381 cmReference
Width182 cmReference
Height201 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
