The Jinma JM-454 is a tractor with a rated output of 45 hp — making it one of the more compact options in its class. It is powered by a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 8-speed gearbox. Listed weight is 2116 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
2116 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
45 hp
Recorded weight
2116 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerJinmaReference
Compact Utility tractorReference
Built in Yancheng City, ChinaReference
Four-wheel driveReference
Engine
Jinma 3.0L 3-cyl dieselReference
Engine33.6 kWReference
JinmaReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke105 x 117 mmReference
Power33.6 kWReference
Rated RPM2200Reference
Transmission
8-speedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift764 kgReference
Rear PTOliveReference
Rear PTO Type540/720/1000Reference
Dimensions
Wheelbase194 cmReference
Weight2116 kgReference
Front tire8.3-20Reference
Rear tire12.4-28Reference
Ag front8.3-20Reference
Ag rear12.4-28Reference
Length382 cmReference
Width162 cmReference
Height206 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
