Industrial Tractor · 1960Unverified

John Deere 1010 Crawler

Name: John Deere 1010 Crawler
Brand: John Deere

John Deere 1010 Crawler — Industrial Crawler tractor · 40 hp. Reference specifications; pending source verification.

The John Deere 1010 Crawler is a compact industrial tractor with a rated power of 40 hp. It was manufactured from 1960 to 1964 and features a 4-cylinder diesel liquid-cooled engine, which drives a 4-speed gearbox through a tracked undercarriage. The listed weight of this model is 6894 to 6999 pounds. It is intended for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

6894 to 6999 pounds

Catalogue coverage

Variants represented

Richest spec table

78 rows

Recorded power

40 hp

Recorded weight

3127 kg

Transmissions

4-speed gear

Production years

1960-1964

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerJohn DeereReference

Industrial Crawler tractorReference

Built in Dubuque, Iowa, USAReference

Total built15,803 (total)Reference

Total built9,094 (gas)Reference

Total built6,709 (diesel)Reference

DrivecrawlerReference

Steeringmultiple disc clutch and brakeReference

Mechancial contracting band brakesReference

Open operator station.Reference

Variants

1010Windustrial tractorReference

1010Cindustrial crawlerReference

1010CLtrack loaderReference

1010farm tractorReference

1010C Agfarm crawlerReference

Engine

John Deere 1.9L 4-cyl gasolineReference

John Deere 2.4L 4-cyl dieselReference

Fuel tank45.4 LReference

Engine (net)29.8 kWReference

John DeereReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke89 x 76 mmReference

Power (net)29.8 kWReference

Air cleaneroil bathReference

Compression7.9:1Reference

Rated RPM2500Reference

Torque120.7 NmReference

Torque RPM1500Reference

Starter volts12Reference

dieselReference

Displacement2.4 LReference

Bore/Stroke92 x 89 mmReference

Compression19:1Reference

Torque128.8 NmReference

Starter volts24Reference

Transmission

4-speed gearReference

4-speed shuttleReference

TransmissionJohn DeereReference

TypegearReference

Gears4 forward and 1 reverseReference

Clutch279.4mm mechanical dry discReference

TypeshuttleReference

Gears4 forward and reverseReference

Clutchhydraulic wet discReference

Dimensions

Weight6894 to 6999 poundsReference

12-inch tracksReference

Gas Shipping weight3127 kgReference

Diesel Shipping weight3174 kgReference

Gauge121 to 0 cmReference

John Deere 1010 Crawler attachments

bladeReference

1010 Crawler Serial Numbers

196010001Reference

196113692Reference

196223630Reference

196332188Reference

196443900Reference

196553722Reference

Final57312Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundpositiveReference

Batteries1 (gas)Reference

Batteries2 (diesel)Reference

Battery volts12Reference

John Deere 1010 Crawler Tracks

4-roller width30 cmReference

4-roller length on ground149 cmReference

4-roller area on ground0.9 m²Reference

4-roller ground pressure0.3 barReference

5-roller width30 cmReference

5-roller length on ground175 cmReference

5-roller area on ground1.1 m²Reference

5-roller ground pressure0.3 barReference

Width25 cmReference

Width35 cmReference

John Deere 1010 Crawler Height

Hood135 cmReference

Gas Exhaust180 cmReference

Diesel Exhaust188 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
