Tractor · 1967Unverified
John Deere 1020 VU
John Deere 1020 VU — Orchard/Vineyard tractor · 44 hp. Reference specifications; pending source verification.
The John Deere 1020 VU is a compact tractor model rated at 44 hp. Manufactured from 1967 to 1972, it features a 3-cylinder diesel liquid-cooled engine and a two-wheel drive system with an 8-speed gearbox. The listed weight of the tractor is 1710 kg. It is designed for use on plots of approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
1710 kg
Catalogue coverage
Variants represented
2
Richest spec table
38 rows
Recorded power
44 hp
Recorded weight
1710 kg
Transmissions
8-speed gear
Production years
1967-1972
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Orchard/Vineyard tractorReference
Built in Getafe, SpainReference
Two-wheel driveReference
Differential lockmechanical rearReference
Open operator station.Reference
Engine
John Deere 2.5L 3-cyl dieselReference
Engine32.8 kWReference
John DeereReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke98 x 110 mmReference
Power32.8 kWReference
Air cleaneroil bathReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range.Reference
PTO & Hydraulics
Rear TypeIReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2100Reference
Dimensions
Wheelbase160 cmReference
Weight1710 kgReference
Front tire5.50-16Reference
Rear tire11.2/10-28Reference
Ag front5.50-16Reference
Ag rear11.2/10-28Reference
Length309 cmReference
Width98 cmReference
1020 VU Serial Number Location
Serial number plate on the right side of the 1020VU frame, above the front axle.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
