Tractor · 2011Unverified
John Deere 1023E
John Deere 1023E — Model year 2011-20152016-2025 · 24 hp. Reference specifications; pending source verification.
The John Deere 1023E is a compact tractor model with a rated output of 24 hp, making it suitable for smaller-scale applications. The 1023E was manufactured from 2011 to 2025. It features a 3-cylinder diesel liquid-cooled engine, which powers a hydrostatic transmission and drives all four wheels. The listed weight of the 1023E is 610 kg, and it is capable of handling tasks on approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Max power
21.5 hp (3,200 rpm)
Weight
610 kg
Catalogue coverage
Variants represented
2
Richest spec table
136 rows
Recorded power
24 hp
Recorded weight
610 kg
Transmissions
hydrostatic
Production years
2011-2025
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Sub-Compact Utility tractorReference
Built in Augusta, Georgia, USAReference
Original price$11,296 (2011 )Reference
Original price$12,062 (2017 )Reference
Four-wheel driveReference
Differential lockstandardReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Yanmar 0.9L 3-cyl dieselReference
Engine (gross)17.5 kWReference
Yanmar 3TNM72Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement0.9 LReference
Bore/Stroke71 x 74 mmReference
EmissionsInterim Tier IVReference
Rated Power (gross)17.5 kWReference
Fuel systemindirect injectionReference
Air cleanerdry dual stageReference
Pre-heatingglow plugsReference
Rated RPM3200Reference
Operating RPM1400-3370Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity3.7 LReference
Coolant change2000 hReference
Oil capacity2.7 LReference
Oil change200 hReference
Fuel TypeDieselReference
No of CylindersThreeReference
Rated engine speed3,200 rpmReference
Emissions complianceFinal Tier 4Reference
Cylinder linersCast-in-blockReference
Engine torque at rated speed47.7 NmReference
Injection pump typeIndirect injectionReference
AspirationNaturalReference
Bore and stroke74 x 77 mmReference
Compression ratio23.5:1Reference
Cooling systemWater pumpReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity12.3 LReference
Oil typeJD Hy-GardReference
Hydrostatic transmission operated by two foot pedals and left-hand range shift. Tractor must be stopped to shift range.Reference
Transmission TypeE-HSTReference
forward and reverse optionstwo rangeReference
Wheel Drive4WDReference
ClutchWet diskReference
Gear Shift LocationLeft-hand sideReference
PTO & Hydraulics
PTO (claimed)11.4 kWReference
Hydraulic system12.3 LReference
Typeopen centerReference
Capacity12.3 LReference
Pressure137.9 barReference
Valves2 to 3Reference
Total flow23.8 lpmReference
Rear TypeLimited IReference
Rear lift (at ends)650 kgReference
Rear lift (at 24"/610mm)308 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@3200Reference
Mid PTOindependentReference
Mid PTO Type2100Reference
Engine RPM2100@3200Reference
Capacities
Fuel21.2 LReference
Front Axle capacity611.9 kgReference
Rear Axle capacity714.9 kgReference
Fuel tank24 LReference
Crankcase oil volume2.7 LReference
Dimensions
Wheelbase145 cmReference
Weight610 kgReference
Lawn/turf front18x8.5-10Reference
Lawn/turf rear26x12.00-12Reference
Industrial front18x8.5-10Reference
Industrial rear26x12.00-12Reference
Length222 cmReference
Length260 cmReference
Width119 cmReference
Height (hood)105 cmReference
Height (ROPS)199 cmReference
Clearance (front axle)31 cmReference
Flanged rear axleReference
Front tread81 cmReference
Rear tread89 cmReference
Operating610 kgReference
Max front axle611 kgReference
Max rear axle714 kgReference
John Deere 1023E attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
front-end loaderReference
1023E Serial Number Location
On main tractor frame above the right-side front wheel.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA500Reference
Battery volts12Reference
Battery size500 CCAReference
Alternator size40 ampReference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
John Deere D120 loaderReference
John Deere H120 loaderReference
Speeds
With 26x12.00-12 R4 rear tires.Reference
General
Make & ModelYanmar® @ 3TNM74F-NCJTReference
LubricationPressurizedReference
Cruise controlfalseReference
SCV controlJoystick: AvailableReference
Rear tread spacing895 mm\\n35.2 in.Reference
Rollover protective structureType\\nFoldable\\nYesReference
PlatformOne-piece semi flatReference
Power
Max Power21.5 hp (3,200 rpm)Reference
PTO
PTO Power14.9 hpReference
Rear PTO PowerAvailableReference
Rear PTO ControlIndependentReference
Rear PTO RPM540 rpmReference
Mid PTO RPM2,100 rpmReference
Steering & brakes
BrakesWet disc (left-hand pedal)Reference
Steering typePowerReference
Hydraulics
Pump Rated Output (total)24 l/minReference
Hydraulics TypeSingle gearReference
Maximum operating pressure2,000 psiReference
Remote ValvesThreeReference
Steering & Implements flow13.2 L/min (13.2 L/min)Reference
Rear Hitch category (SAE designation)3-Point | Limited Category 1Reference
Dimensions & weight
Ground Clearance195 mmReference
Turning radius2.5 mReference
Overall weight655.9 kgReference
Wheels & tyres
Rear Wheel TypeR3 Turf: 26x12-12\\nR4: 26x12-12Reference
Front Wheel TypeR3 Turf: 18x8.50-10\\nR4: 18x8.5-10Reference
Operator station
Cab AvailabilityfalseReference
Seat SuspensiontrueReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
