John Deere 1026R
John Deere 1026R — 1 Sub-Compact Series · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
654 kg
Hover a source tag to verify
Overview
ManufacturerJohn DeereReference
Sub-Compact Utility tractorReference
Built in Augusta, Georgia, USAReference
Original price was $12,595 in 2011Reference
Four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanial rearReference
Power steeringReference
Disc brakesReference
Two-post ROPS.Reference
Engine
Yanmar 1.1L 3-cyl dieselReference
Engine (gross)18.8 kWReference
Engine (net)17.7 kWReference
Yanmar 3TNV76Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke74 x 81 mmReference
EmissionsInterim Tier IVReference
Rated Power (net)17.7 kWReference
Rated Power (gross)18.8 kWReference
Fuel systemindirect injectionReference
Air cleanerdual stage dryReference
Pre-heatingglow plugsReference
Compression23.5:1Reference
Rated RPM3200Reference
Operating RPM1400-3370Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity3.7 LReference
Coolant change2000 hReference
Oil capacity2.7 LReference
Oil change200 hReference
Image courtesy of Doug EasterlundReference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
Oil capacity12.3 LReference
Oil typeJD Hy-GardReference
Hydrostatic transmission operated by two foot pedals, left-hand range shift lever, and cruise control. Tractor must be stopped to shift range.Reference
PTO & Hydraulics
PTO (claimed)13.4 kWReference
Hydraulic system12.3 LReference
Typeopen centerReference
Capacity12.3 LReference
Pressure137.9 barReference
Valves2 to 3Reference
Total flow23.8 lpmReference
Rear TypeLimited IReference
Controlposition controlReference
Rear lift (at ends)650 kgReference
Rear lift (at 24"/610mm)308 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@3200Reference
Mid PTOindependentReference
Mid PTO Type2100Reference
Engine RPM2100@3200Reference
Capacities
Fuel21.2 LReference
Dimensions
Wheelbase145 cmReference
Weight654 kgReference
Lawn/turf front18x8.5-10Reference
Lawn/turf rear26x12.00-12Reference
Industrial front18x8.5-10Reference
Industrial rear26x12.00-12Reference
Length222 cmReference
Length260 cmReference
Width119 cmReference
Height (hood)105 cmReference
Height (ROPS)199 cmReference
Clearance (front axle)31 cmReference
Flanged rear axleReference
Front tread81 cmReference
Rear tread89 cmReference
Operating654 kgReference
Max front axle611 kgReference
Max rear axle714 kgReference
John Deere 1026R attachments
54" mid-mount mower deckReference
60" mid-mount mower deckReference
front-end loaderReference
1026R Serial Number Location
Serial number plate on the right side of main tractor frame above the front axle.Reference
1026R Serial Numbers
2011110001Reference
2012210001Reference
2013310001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA500Reference
Battery volts12Reference
Attachment overview
54" mid-mount mower deckReference
60" mid-mount mower deckReference
John Deere D120 loaderReference
John Deere H120 loaderReference
Speeds
With 26x12.00-12 R4 rear tires.Reference
