Tractor · 1996Unverified
John Deere 1046
John Deere 1046 — 46 Series · 37 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
37 hp
Weight
1119 kg
Hover a source tag to verify
Overview
DistributorJohn DeereReference
ManufacturerGoldiniReference
Compact Utility tractorReference
Built in ItalyReference
The John Deere 1046 is the same as the Goldoni Idea 40.Reference
Four-wheel driveReference
Differential lockhydraulic rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Two-post mid-mount folding ROPS.Reference
Engine
Lombardini 1.6L 3-cyl dieselReference
Fuel tank20.1 LReference
Engine27.6 kWReference
Lombardini LDW 1503Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.6 LReference
Bore/Stroke88 x 85 mmReference
Power27.6 kWReference
Air cleanerdryReference
Rated RPM2800Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed synchronizedReference
TypesynchronizedReference
Gears12 forward and 4 reverseReference
Clutch191mm hydraulic discReference
Four gears in three ranges, plus reverse range.Reference
PTO & Hydraulics
Rear TypeINReference
Rear lift (at ends)1000 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2607Reference
Engine RPM1000@2615Reference
Dimensions
Wheelbase160 cmReference
Weight1119 kgReference
Front tire7.00-12Reference
Rear tire12.4R20Reference
Standard tires (ag)Front: 7.00-12. Rear: 12.4R20Reference
Length292 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
