Tractor · 2003Unverified

John Deere 1047

Name: John Deere 1047
Brand: John Deere

John Deere 1047 — 47 Series · 33 hp. Reference specifications; pending source verification.

The John Deere 1047 is a compact tractor with a rated output of 33 hp, featuring a 3-cylinder diesel liquid-cooled engine. Produced between 2003 and 2004, the 1047 is equipped with a four-wheel drive system and a 12-speed gearbox. Its capabilities are suited to tasks on small to medium-sized farms, covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Catalogue coverage

Variants represented

Richest spec table

41 rows

Recorded power

33 hp

Transmissions

12-speed synchronized

Production years

2003-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorJohn DeereReference

ManufacturerGoldiniReference

Compact Utility tractorReference

Built in ItalyReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Hydraulic wet disc brakesReference

Two-post mid-mount folding ROPS.Reference

Engine

Lombardini 1.6L 3-cyl dieselReference

Engine24.6 kWReference

Lombardini LDW 1503Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.6 LReference

Bore/Stroke88 x 85 mmReference

Power24.6 kWReference

Air cleanerdryReference

Rated RPM2800Reference

Torque93.0 NmReference

Torque RPM2000Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchronizedReference

TypesynchronizedReference

Gears12 forward and reverseReference

Clutch228mm mechanical dry discReference

PTO & Hydraulics

Pressure150.0 barReference

Pump flow29.9 lpmReference

Rear TypeI/INReference

Rear lift (at ends)1349 kgReference

Rear lift (at 24"/610mm)980 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Engine RPM540@2608Reference

Engine RPM1000@2620Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps55Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
